Intrinsic versus imposed curvature in cyclical oligomers: the portal protein of bacteriophage SPP1.

Large cyclical oligomers may be formed by (curvi-) linear polymerization of monomers until the n(th) monomer locks in with the first member of the chain. The subunits in incomplete structures exhibit a natural curvature with respect to each other which can be perturbed when the oligomer closes cyclically. Using cryo-electron microscopy and multivariate statistical image processing we report herein a direct structural observation of this effect. A sub-population (approximately 15%) of incomplete oligomers was found within a sample of SPP1 bacteriophage portal proteins embedded in vitreous ice. Whereas the curvature between adjacent subunits of the closed circular 13-fold symmetric oligomer is 27.7 degrees, in these incomplete oligomers the angle is only 25.8 degrees, a value which almost allows for a 14-subunit cyclical arrangement. A simple model for the association of large cyclical oligomers is suggested by our data.
