Centro de Biotecnología-FEMSA, Tecnológico de Monterrey at Monterrey, Monterrey, México.
PLoS One. 2010 Jul 22;5(7):e11694. doi: 10.1371/journal.pone.0011694.
The A/H1N1/2009 influenza pandemic made evident the need for faster and higher-yield methods for the production of influenza vaccines. Platforms based on virus culture in mammalian or insect cells are currently under investigation. Alternatively, expression of fragments of the hemagglutinin (HA) protein in prokaryotic systems can potentially be the most efficacious strategy for the manufacture of large quantities of influenza vaccine in a short period of time. Despite experimental evidence on the immunogenic potential of HA protein constructs expressed in bacteria, it is still generally accepted that glycosylation should be a requirement for vaccine efficacy.
METHODOLOGY/PRINCIPAL FINDINGS: We expressed the globular HA receptor binding domain, referred to here as HA(63-286)-RBD, of the influenza A/H1N1/2009 virus in Escherichia coli using a simple, robust and scalable process. The recombinant protein was refolded and purified from the insoluble fraction of the cellular lysate as a single species. Recombinant HA(63-286)-RBD appears to be properly folded, as shown by analytical ultracentrifugation and bio-recognition assays. It binds specifically to serum antibodies from influenza A/H1N1/2009 patients and was found to be immunogenic, to be capable of triggering the production of neutralizing antibodies, and to have protective activity in the ferret model.
CONCLUSIONS/SIGNIFICANCE: Projections based on our production/purification data indicate that this strategy could yield up to half a billion doses of vaccine per month in a medium-scale pharmaceutical production facility equipped for bacterial culture. Also, our findings demonstrate that glycosylation is not a mandatory requirement for influenza vaccine efficacy.
甲型 H1N1/2009 流感大流行凸显了需要更快、更高产的方法来生产流感疫苗。目前正在研究基于哺乳动物或昆虫细胞培养的病毒的平台。或者,在原核系统中表达血凝素 (HA) 蛋白片段可能是在短时间内制造大量流感疫苗的最有效策略。尽管有实验证据表明在细菌中表达的 HA 蛋白构建体具有免疫原性,但人们仍然普遍认为糖基化应该是疫苗效力的要求。
方法/主要发现:我们使用简单、稳健和可扩展的过程在大肠杆菌中表达了流感 A/H1N1/2009 病毒的球形 HA 受体结合域,这里称为 HA(63-286)-RBD。重组蛋白从细胞裂解物的不可溶部分中作为单一物种进行复性和纯化。重组 HA(63-286)-RBD 似乎正确折叠,如分析超速离心和生物识别分析所示。它特异性地与来自甲型 H1N1/2009 患者的血清抗体结合,并且具有免疫原性,能够触发中和抗体的产生,并在雪貂模型中具有保护活性。
结论/意义:基于我们的生产/纯化数据的预测表明,这种策略可以在配备有细菌培养设备的中等规模制药生产设施中每月生产多达 5 亿剂疫苗。此外,我们的研究结果表明,糖基化不是流感疫苗效力的强制性要求。
