Department of Cell Biology, University of Calabria, Arcavacata di Rende, Italy.
Mol Biotechnol. 2013 Jun;54(2):724-36. doi: 10.1007/s12033-012-9586-8.
The OCTN subfamily includes OCTN1, 2, and 3 which are structurally and functionally related. These transporters are involved in maintenance of the carnitine homeostasis, which is essential in mammals for fatty acid β-oxidation, VLDL assembly, post-translational modifications, and other essential functions. Indeed, defects of these transporters lead to severe pathologies. OCTN1 and OCTN2 are expressed in many human tissues, while OCTN3 gene has been identified only in mouse and rat. The transporters mediate transport of carnitine and other substrates with different efficiencies and mechanisms. In order to over express the three proteins, a screening of many combinations of E. coli strains with plasmid constructs has been conducted. Only Rosetta(DE3) or Rosettagami2(DE3) gave significant expression. Higher protein amounts were firstly obtained with pET-41a(+) or pGEX-4T1 carrying fusion protein tags which required additional purification passages. Vectors carrying only a 6His tag, suitable for single passage purification, were preferred even though they lead to lower initial expression levels. Expressions were then increased optimizing several critical parameters. hOCTN1 was obtained with pH6EX3 in RosettaGami2(DE3)pLysS. hOCTN2 and mOCTN3 were obtained using pET-21a(+) in Rosetta(DE3). In particular, hOCTN2 was expressed only after codon bias, substituting the second triplet CGG with AAA (R2K mutant). The best growth conditions for hOCTN1 and mOCTN3 were 28 °C and 6 h of induction, while 4 h of induction for hOCTN2R2K. The proteins collected in the insoluble fraction of cell lysates, solubilized with sarkosyl, were purified by Ni-chelating chromatography. Final yield was 2.0, 3.0, or 3.5 mg/l of cell culture for mOCTN3, hOCTN1, or hOCTN2R2K. The data indicated that, in spite of the close evolutionary relations, several factors play different critical roles in bacterial expression of the three proteins, thus general criteria cannot be underlined. However, the strategy of dealing with related proteins revealed to be finally successful for over expressing all the three subfamily members.
OCTN 亚家族包括 OCTN1、2 和 3,它们在结构和功能上相关。这些转运蛋白参与肉碱稳态的维持,这对于哺乳动物的脂肪酸 β-氧化、VLDL 组装、翻译后修饰和其他基本功能至关重要。事实上,这些转运蛋白的缺陷会导致严重的病理。OCTN1 和 OCTN2 在许多人体组织中表达,而 OCTN3 基因仅在小鼠和大鼠中被发现。转运蛋白介导肉碱和其他具有不同效率和机制的底物的转运。为了过表达这三种蛋白质,已经对许多带有质粒构建体的大肠杆菌菌株进行了筛选。只有 Rosetta(DE3)或 Rosettagami2(DE3) 给出了显著的表达。使用带有融合蛋白标签的 pET-41a(+)或 pGEX-4T1 首先获得了更高的蛋白量,这需要额外的纯化步骤。仅携带 6His 标签的载体,适用于单步纯化,即使它们导致初始表达水平较低,也被优先选择。通过优化几个关键参数来增加表达量。hOCTN1 是在 RosettaGami2(DE3)pLysS 中用 pH6EX3 获得的。hOCTN2 和 mOCTN3 是使用 pET-21a(+)在 Rosetta(DE3)中获得的。特别是,hOCTN2 仅在替换第二个三联体 CGG 为 AAA (R2K 突变体)后才表达。hOCTN1 和 mOCTN3 的最佳生长条件是 28°C 和 6 小时诱导,而 hOCTN2R2K 则为 4 小时诱导。在细胞裂解物的不溶性部分收集的蛋白,用 sarcosyl 溶解,通过 Ni-螯合色谱进行纯化。最终产量为 2.0、3.0 或 3.5mg/l 的细胞培养物,用于 mOCTN3、hOCTN1 或 hOCTN2R2K。数据表明,尽管进化关系密切,但在三种蛋白质的细菌表达中,有几个因素发挥着不同的关键作用,因此不能强调一般标准。然而,处理相关蛋白的策略最终被证明对过表达三种亚家族成员都很成功。
