通过数学建模优化灌注中空纤维生物反应器中的细胞聚集体扩增

Optimising cell aggregate expansion in a perfused hollow fibre bioreactor via mathematical modelling.

作者信息

Chapman Lloyd A C, Shipley Rebecca J, Whiteley Jonathan P, Ellis Marianne J, Byrne Helen M, Waters Sarah L

机构信息

Mathematical Institute, University of Oxford, Oxford, United Kingdom; Department of Computer Science, University of Oxford, Oxford, United Kingdom.

Department of Mechanical Engineering, UCL, London, United Kingdom.

出版信息

PLoS One. 2014 Aug 26;9(8):e105813. doi: 10.1371/journal.pone.0105813. eCollection 2014.

Abstract

The need for efficient and controlled expansion of cell populations is paramount in tissue engineering. Hollow fibre bioreactors (HFBs) have the potential to meet this need, but only with improved understanding of how operating conditions and cell seeding strategy affect cell proliferation in the bioreactor. This study is designed to assess the effects of two key operating parameters (the flow rate of culture medium into the fibre lumen and the fluid pressure imposed at the lumen outlet), together with the cell seeding distribution, on cell population growth in a single-fibre HFB. This is achieved using mathematical modelling and numerical methods to simulate the growth of cell aggregates along the outer surface of the fibre in response to the local oxygen concentration and fluid shear stress. The oxygen delivery to the cell aggregates and the fluid shear stress increase as the flow rate and pressure imposed at the lumen outlet are increased. Although the increased oxygen delivery promotes growth, the higher fluid shear stress can lead to cell death. For a given cell type and initial aggregate distribution, the operating parameters that give the most rapid overall growth can be identified from simulations. For example, when aggregates of rat cardiomyocytes that can tolerate shear stresses of up to 0:05 Pa are evenly distributed along the fibre, the inlet flow rate and outlet pressure that maximise the overall growth rate are predicted to be in the ranges 2.75 x 10(-5) m(2) s(-1) to 3 x 10(-5) m(2) s(-1) (equivalent to 2.07 ml min(-1) to 2.26 ml min(-1)) and 1.077 x 10(5) Pa to 1.083 x 10(5) Pa (or 15.6 psi to 15.7 psi) respectively. The combined effects of the seeding distribution and flow on the growth are also investigated and the optimal conditions for growth found to depend on the shear tolerance and oxygen demands of the cells.

摘要

在组织工程中,高效且可控地扩增细胞群体的需求至关重要。中空纤维生物反应器(HFBs)有潜力满足这一需求,但前提是要更好地理解操作条件和细胞接种策略如何影响生物反应器中的细胞增殖。本研究旨在评估两个关键操作参数(培养基流入纤维内腔的流速和施加于内腔出口的流体压力)以及细胞接种分布对单纤维HFB中细胞群体生长的影响。这是通过数学建模和数值方法来实现的,以模拟细胞聚集体沿纤维外表面的生长情况,该生长是对局部氧浓度和流体剪切应力的响应。随着内腔出口处施加的流速和压力增加,输送到细胞聚集体的氧气量以及流体剪切应力都会增加。虽然增加的氧气输送促进生长,但较高的流体剪切应力可能导致细胞死亡。对于给定的细胞类型和初始聚集体分布,可以从模拟中确定能实现最快整体生长的操作参数。例如,当能够耐受高达0.05 Pa剪切应力的大鼠心肌细胞聚集体沿纤维均匀分布时,预测使整体生长速率最大化的入口流速和出口压力分别在2.75×10⁻⁵ m² s⁻¹至3×10⁻⁵ m² s⁻¹(相当于2.07 ml min⁻¹至2.26 ml min⁻¹)以及1.077×10⁵ Pa至1.083×10⁵ Pa(或15.6 psi至15.7 psi)范围内。还研究了接种分布和流动对生长的综合影响,发现生长的最佳条件取决于细胞的剪切耐受性和氧气需求。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/aad0/4144904/4d11e986f953/pone.0105813.g001.jpg
