He Jiliang, Tan Guoqing, Zhou Dongsheng, Sun Liang, Li Qinghu, Yang Yongliang, Liu Ping
From the Department of Orthopaedic, Shandong Provincial Hospital Affiliated to Shandong University (JH, DZ, QL, YY); Department of Orthopaedic, Affiliated Hospital of Shandong University of Traditional Chinese Medicine (GT); Department of Urology, Shandong Provincial Hospital Affiliated to Shandong University (LS); and Department of Pharmacy, Shandong Provincial Hospital Affiliated to Shandong University, Jinan, China (PL).
Medicine (Baltimore). 2016 Jan;95(2):e2470. doi: 10.1097/MD.0000000000002470.
Percutaneous screw insertion for minimally displaced or reducible acetabular fracture using x-ray fluoroscopy and computer-assisted navigation system has been advocated by some authors. The purpose of this study was to compare intraoperative conditions and clinical results between isocentric C-arm 3-dimensional (Iso-C 3D) fluoroscopy and conventional fluoroscopy for percutaneous retrograde screwing of acetabular anterior column fracture.A prospective cohort study was conducted. A total of 22 patients were assigned to 2 different groups: 10 patients in the Iso-C 3D navigation group and 12 patients in the conventional group. The operative time, fluoroscopic time, time of screw insertion, blood loss, and accuracy were analyzed between the 2 groups.There were significant differences in operative time, screw insertion time, fluoroscopy time, and mean blood loss between the 2 groups. Totally 2 of 12 (16.7%) screws were misplaced in the conventional fluoroscopy group, and all 10 screws were in safe zones in the navigation group. Percutaneous screw fixation using the Iso-C 3D computer-assisted navigation system significantly reduced the intraoperative fluoroscopy time and blood loss in percutaneous screwing for acetabular anterior column fracture.The Iso-C 3D computer-assisted navigation system provided a reliable and effective method for percutaneous screw insertion in acetabular anterior column fractures compared to conventional fluoroscopy.
一些作者提倡使用X线透视和计算机辅助导航系统经皮螺钉置入治疗轻度移位或可复位的髋臼骨折。本研究的目的是比较等中心C形臂三维(Iso-C 3D)透视和传统透视在髋臼前柱骨折经皮逆行螺钉置入术中的手术情况和临床结果。进行了一项前瞻性队列研究。共22例患者被分为2个不同组:Iso-C 3D导航组10例患者,传统组12例患者。分析了两组之间的手术时间、透视时间、螺钉置入时间、失血量和准确性。两组之间在手术时间、螺钉置入时间、透视时间和平均失血量方面存在显著差异。在传统透视组中,12枚螺钉中有2枚(16.7%)位置不当,而在导航组中所有10枚螺钉均处于安全区域。使用Iso-C 3D计算机辅助导航系统经皮螺钉固定显著减少了髋臼前柱骨折经皮螺钉置入术中的透视时间和失血量。与传统透视相比,Iso-C 3D计算机辅助导航系统为髋臼前柱骨折经皮螺钉置入提供了一种可靠且有效的方法。
