Frankowski Marcin
Department of Water and Soil Analysis, Adam Mickiewicz University in Poznań, Umultowska 89b, 61-614, Poznań, Poland.
Environ Sci Pollut Res Int. 2016 Jun;23(11):11046-11057. doi: 10.1007/s11356-016-6274-4. Epub 2016 Feb 23.
The results of inorganic and organic anion concentrations in samples of soils and plant parts of Betula pendula (tap roots, lateral roots, stem, twigs, leaves), in the bioavailable fraction, are presented in this study. An ion chromatography method was applied for the first time in the simultaneous determination of inorganic and organic anions, as an effective tool for qualitative and quantitative analysis of samples with different matrix. A linear gradient elution with potassium hydroxide allowed for the separation of both inorganic and organic ions such as: F(-), CH3COO(-), HCOO(-), Cl(-), NO2 (-), Br(-) and NO3 (-), SO4 (2-), CH2(COO)2 (2-), C2O4 (2-), PO4 (3-) and C3H5O(COO)3 (3-). The samples of soils and plant parts of B. pendula from the area of the Wielkopolski National Park (WNP) and the Chemical Plant in Luboń (LU; protected vs. contaminated area) were selected for the study. The obtained results indicated that such inorganic ions as: F(-), Cl(-), NO3 (-) and PO4 (3-) are quite easily transported from soil to leaves. In contrast, the mechanism of migration could not be clearly defined for SO4 (2-) because the ion was retained in roots of many of the analysed samples. Significantly higher bioavailability of inorganic ions was observed for samples collected from the area of the WNP. Phosphates were the only ions which showed no variation in their concentrations between the two sampling sites, both for soils and plant parts of B. pendula. None of the organic anions was detected in soil samples. The acetate, formate, malonate, oxalate and citrate ions were detected in all leaf samples. The statistical analysis allowed the author to determine the mechanism of ion migration and accumulation in leaves and, additionally, determine the variation in the occurrence of inorganic and organic ions depending on the sampling site (WNP vs. LU). The results of the statistical analysis were confirmed by the bioacumulation (BF) and translocation (TF) factors.
本研究展示了白桦(主根、侧根、茎、小枝、叶片)土壤和植物部分样本中生物可利用部分的无机和有机阴离子浓度结果。离子色谱法首次应用于同时测定无机和有机阴离子,作为对不同基质样品进行定性和定量分析的有效工具。氢氧化钾线性梯度洗脱可分离无机和有机离子,如:F(-)、CH3COO(-)、HCOO(-)、Cl(-)、NO2 (-)、Br(-)、NO3 (-)、SO4 (2-)、CH2(COO)2 (2-)、C2O4 (2-)、PO4 (3-) 和 C3H5O(COO)3 (3-)。选取了大波兰国家公园(WNP)区域和卢邦化工厂(LU;保护区与污染区)的白桦土壤和植物部分样本进行研究。所得结果表明,诸如 F(-)、Cl(-)、NO3 (-) 和 PO4 (3-) 等无机离子相当容易从土壤转运至叶片。相比之下,SO4 (2-) 的迁移机制无法明确界定,因为该离子在许多分析样本的根部被保留。在 WNP 区域采集的样本中观察到无机离子的生物有效性显著更高。磷酸盐是唯一在两个采样地点(土壤和白桦植物部分)浓度均无变化的离子。在土壤样本中未检测到任何有机阴离子。在所有叶片样本中均检测到乙酸根、甲酸根、丙二酸根、草酸根和柠檬酸根离子。统计分析使作者能够确定离子在叶片中的迁移和积累机制,此外,还能确定无机和有机离子的出现情况因采样地点(WNP 与 LU)的差异。生物累积(BF)和转运(TF)因子证实了统计分析结果。
