Prenatal diagnoses of an uncommon isolated obstructed supracardiac total anomalous pulmonary venous connection: Case report and review of the literature (CARE compliant).

INTRODUCTION

Total anomalous pulmonary venous connection is an uncommon congenital heart disease. Four types are described based on the site of pulmonary venous drainage: supracardiac, cardiac, infradiaphragmathic, and mixed connection. In most cases of supracardiac type, the common venous confluence drains through an ascending left vertical vein into the brachiocephalic vein, right superior vena cava, and then into the right atrium. Anomalous connection of the pulmonary venous confluence directly to the right SVC, especially the obstructed form is an unusual and severe supracardiac variant. The prenatal diagnosis is challenging.

PATIENT CONCERNS

We present a case report of a fetus diagnosed with TAPVC at 23 gestational weeks.

DIAGNOSIS INTERVENTIONS

The 4-chamber view showed a small left atrium, with a "smooth" posterior wall and the absence of pulmonary vein connection. This is the first case of prenatally diagnosed isolated, obstructed supracardiac type with drainage directly into the right superior vena cava.

CONCLUSION

The obstetrician and fetal cardiologist should be cautious at the direct and indirect echocardiographic signs of this condition. A prenatal diagnose of isolated, obstructed form is important for adequate planning of delivery and postnatal surgery in a tertiary center.
