Three-Dimensional Reconstruction Computed Tomography Evaluation of the Tunnel Location and Angle in Anatomic Single-Bundle Anterior Cruciate Ligament Reconstruction: A Comparison of the Anteromedial Portal and Outside-in Techniques.

PURPOSE

The purpose of this study was to compare the geometry and position of the femoral tunnel between the anteromedial portal (AMP) and outside-in (OI) techniques after anatomic single-bundle anterior cruciate ligament (ACL) reconstruction.

MATERIALS AND METHODS

We evaluated 82 patients undergoing single-bundle ACL reconstruction with hamstring autografts using either the AMP (n=40) or OI (n=42) technique. The locations of the tunnel apertures were assessed by postoperative 3-dimensional computed tomography imaging. The femoral graft bending angle, femoral tunnel aperture shape, femoral tunnel length, and posterior wall breakage were also measured.

RESULTS

The mean femoral tunnel position parallel to the Blumensaat line was more caudally positioned in the AMP group than in the OI group (p=0.025) The mean femoral graft angle in the OI group (99.6°±7.1°) was significantly more acute than that of the AMP group (108.9°±10.2°, p<0.001). The mean height/width ratio of the AMP group (1.21±0.20) was significantly more ellipsoidal than that of the OI group (1.07±0.09, p<0.001).

CONCLUSIONS

The mean femoral tunnel position was significantly shallower in the AMP technique than in the OI technique. The OI technique might be more disadvantageous than the AMP technique in terms of the more acute bending angle.
