Jiang Jian, Wang Ke, Xu Yufeng, Liu Jianxin, Luo Jingjing, Tao Xin, Wang Xiaoying
Department of Radiology, Peking University First Hospital, Beijing, China (mainland).
Med Sci Monit. 2017 Apr 16;23:1834-1841. doi: 10.12659/msm.904129.
BACKGROUND The aim of this study was to investigate the feasibility of a split-bolus combined phase contrast-enhanced computed tomography protocol in evaluation of liver vasculature in hepatocellular carcinoma (HCC) patients for the purpose of surgery guidance. MATERIAL AND METHODS Two groups of patients were recruited for the study: 24 consecutive cases of HCC who underwent multiphasic CT examination, and 22 consecutive cases who afterwards underwent split-bolus combined phase CT examination. The multiphasic protocol included an unenhanced scan and 3 image acquisitions after contrast injection. The injection of contrast medium was 440 mgI/kg in a single bolus. The split-bolus combined phase protocol included unenhanced scan and combined phase. The injection of contrast medium was 440 mgI/kg for the first bolus and 220 mgI/kg for the second bolus. The vascular delineation was evaluated with Likert scales. The CT values were measured, and the contrast-to-noise ratio (CNR) was calculated. We also compared the effective radiation dose (ED) of the 2 protocols. RESULTS All mean CT values were significantly higher in the split-bolus protocol than in the multiphasic protocol (all P.05). The ED was significantly lower in the split-bolus protocol, corresponding to a dose reduction of 66% compared to the multiphasic protocol (P<.05). The scores of the branches of the hepatic vein in the split-bolus protocol were not lower than those in the multiphasic protocol. CONCLUSIONS For the preoperative HCC patients, the split-bolus combined phase CT examination meets the diagnostic requirement of surgical planning, with approximately 60% reduction in the radiation dose.
背景 本研究的目的是探讨采用团注分割联合相位对比增强计算机断层扫描(CT)方案评估肝细胞癌(HCC)患者肝血管系统以指导手术的可行性。
材料与方法 本研究招募了两组患者:连续24例接受多期CT检查的HCC患者,以及随后连续22例接受团注分割联合相位CT检查的患者。多期扫描方案包括平扫及注射对比剂后的3次图像采集。对比剂以440 mgI/kg的剂量单次团注。团注分割联合相位扫描方案包括平扫及联合相位扫描。首次团注对比剂的剂量为440 mgI/kg,第二次为220 mgI/kg。采用Likert量表评估血管的显示情况。测量CT值并计算对比噪声比(CNR)。我们还比较了两种扫描方案的有效辐射剂量(ED)。
结果 团注分割扫描方案的所有平均CT值均显著高于多期扫描方案(所有P<0.05)。团注分割扫描方案的ED显著更低,与多期扫描方案相比剂量降低了66%(P<0.05)。团注分割扫描方案中肝静脉分支的评分不低于多期扫描方案。
结论 对于术前HCC患者,团注分割联合相位CT检查满足手术规划的诊断要求,且辐射剂量降低约60%。
