Orr David, Percy Jonathan M, Harrison Zoë A
WestCHEM Department of Pure and Applied Chemistry , University of Strathclyde , Thomas Graham Building, 295 Cathedral Street , Glasgow , G1 1XL , UK . Email:
Refractory Respiratory Inflammation DPU , GlaxoSmithKline Medicines Research Centre , Gunnels Wood Road , Stevenage , SG1 2NY , UK.
Chem Sci. 2016 Oct 1;7(10):6369-6380. doi: 10.1039/c6sc01289b. Epub 2016 Jun 16.
Electronic structure calculations have been used for the effective triage of substituent effects on difluorinated vinylcyclopropane precursors and their ability to undergo vinyl cyclopropane rearrangements (VCPR). Groups which effectively stabilised radicals, specifically heteroarenes, were found to result in the lowest energy barriers. Ten novel precursors were synthesised to test the accuracy of computational predictions; the most reactive species which contained heteroarenes underwent thermal rearrangements at room temperature to afford novel difluorocyclopentenes and fluorinated benzocycloheptadienes through competing VCPR and [3,3]-rearrangement pathways, respectively. More controlled rearrangement of ethyl 3-(1'(2'2'-difluoro-3'-benzo[][1,3]dioxol-5-yl)cyclopropyl)propenoate () allowed these competing pathways to be monitored at the same time and activation energies for both reactions were determined; = (23.4 ± 0.2) kcal mol and = (24.9 ± 0.3) kcal mol. Comparing our calculated activation energies with these parameters showed that no single method stood out as the most accurate for predicting barrier heights; (U)M05-2X/6-31+G* methodology remained the best for VCPR but M06-2X/6-31G* was better for the [3,3]-rearrangement. The consistency observed with (U)B3LYP/6-31G* calculations meant that it came closest to a universal method for dealing with these systems. The developed computational design model correctly predicted the observed selectivity of rearrangement pathways for both our system and literature compounds.
电子结构计算已用于有效筛选取代基对二氟乙烯基环丙烷前体的影响及其进行乙烯基环丙烷重排(VCPR)的能力。发现能有效稳定自由基的基团,特别是杂芳烃,会导致最低的能垒。合成了十种新型前体以测试计算预测的准确性;含有杂芳烃的最活泼物种在室温下发生热重排,分别通过竞争性的VCPR和[3,3] - 重排途径得到新型二氟环戊烯和氟化苯并环庚二烯。对3 - (1'(2',2'-二氟-3'-苯并[][1,3]二氧杂环戊烯-5-基)环丙基)丙烯酸乙酯()进行更可控的重排,使得可以同时监测这些竞争途径,并确定了两个反应的活化能; = (23.4±0.2)kcal/mol和 = (24.9±0.3)kcal/mol。将我们计算的活化能与这些参数进行比较表明,没有一种单一方法在预测势垒高度方面表现出最准确;(U)M05 - 2X/6 - 31 + G方法对于VCPR仍然是最好的,但M06 - 2X/6 - 31G对于[3,3] - 重排更好。与(U)B3LYP/6 - 31G*计算观察到的一致性意味着它最接近处理这些体系的通用方法。所开发的计算设计模型正确地预测了我们的体系和文献化合物中重排途径的观察到的选择性。
