Stock Veronika, Schmidlin Patrick R, Merk Susanne, Wagner Christina, Roos Malgorzata, Eichberger Marlis, Stawarczyk Bogna
Department of Prosthodontics, Dental School, Ludwig-Maximilians-University Munich, Goethestrasse 70, Munich 80336, Germany.
Clinic of Preventive Dentistry, Periodontology and Cariology, Center of Dental Medicine, University of Zurich, Plattenstrasse 11, Zurich 8032, Switzerland.
Materials (Basel). 2016 Mar 10;9(3):187. doi: 10.3390/ma9030187.
In prosthetic dentistry, double crown systems have proved their suitability as retainers for removable partial dentures. However, investigations in this context, regarding polyetheretherketone, are scarce. Therefore, the aim of this study was to test the retention force (RF) between polyetheretherketone (PEEK) primary and cobalt-chromium (CoCr), zirconia (ZrO₂) and galvanic (GAL) secondary crowns with three different tapers. Primary PEEK-crowns were milled with the tapers 0°, 1°, and 2° (n = 10/taper, respectively). Afterwards, 90 secondary crowns were fabricated: (i) 30 CoCr-crowns milled from Ceramill Sintron (AmannGirrbach, Koblach, Austria) (n = 10/taper), (ii) 30 ZrO₂-crowns milled from Ceramill ZI (AmannGirrbach, Koblach, Austria) (n = 10/taper), and (iii) 30 GAL-crowns made using electroforming (n = 10/taper). RF was measured in a pull-off test (20 pull-offs/specimen) and data were analyzed using 2-/1-way Analysis of Variance (ANOVA) followed by the Tukey-Honestly Significant Difference (HSD) post hoc test and linear regression analyses ( < 0.05). The measured mean RF values ranged between 9.6 and 38.2 N. With regard to the 0°, 1°, and 2° tapered crowns, no statistically significant differences between CoCr and ZrO₂ were observed ( > 0.141). At 0° taper, no differences in retention forces between GAL, CrCr, and ZrO₂ crowns were found ( = 0.075). However, at 1° and 2° taper, lower RF for GAL-crowns were observed ( < 0.009, < 0.001, respectively). According to this laboratory study, PEEK might be a suitable material for primary crowns, regardless of the taper and the material of secondary crown. Long-term results, however, are still necessary.
在口腔修复学中,双冠系统已证明其作为可摘局部义齿固位体的适用性。然而,关于聚醚醚酮在这方面的研究却很少。因此,本研究的目的是测试聚醚醚酮(PEEK)基冠与钴铬(CoCr)、氧化锆(ZrO₂)和电镀(GAL)二级冠之间在三种不同锥度下的固位力(RF)。PEEK基冠采用0°、1°和2°的锥度进行铣削加工(每种锥度n = 10)。之后,制作了90个二级冠:(i)30个由Ceramill Sintron(奥地利科布拉克的阿曼吉尔巴赫公司)铣削而成的CoCr冠(每种锥度n = 10),(ii)30个由Ceramill ZI(奥地利科布拉克的阿曼吉尔巴赫公司)铣削而成的ZrO₂冠(每种锥度n = 10),以及(iii)30个采用电铸法制作的GAL冠(每种锥度n = 10)。通过拉脱试验测量固位力(20次拉脱/样本),并使用双因素/单因素方差分析(ANOVA)对数据进行分析,随后进行Tukey - 真实显著差异(HSD)事后检验和线性回归分析(α < 0.05)。测得的平均固位力值在9.6至38.2 N之间。对于0°、1°和2°锥度的冠,CoCr和ZrO₂之间未观察到统计学上的显著差异(P > 0.141)。在0°锥度时,GAL、CoCr和ZrO₂冠之间的固位力没有差异(P = 0.075)。然而,在1°和2°锥度时,观察到GAL冠的固位力较低(分别为P < 0.009,P < 0.001)。根据这项实验室研究,无论锥度和二级冠的材料如何,PEEK可能是基冠的合适材料。然而,仍需要长期结果。
