Son Seon Yong, Cho Kwang-Chun, Cho Pyunggoo, Lee Ju Hyung, Myoung Seong Uk, Choi Jai Ho
Department of Neurosurgery, Bundang Jesaeng General Hospital, Sungnam, Korea.
Department of Radiology, Bundang Jesaeng General Hospital, Sungnam, Korea.
J Cerebrovasc Endovasc Neurosurg. 2017 Dec;19(4):276-283. doi: 10.7461/jcen.2017.19.4.276. Epub 2017 Dec 31.
We aimed to introduce our method involving prepuncture ultrasound scan for cannulation of the common femoral artery (CFA) during transfemoral cerebral angiography (TFCA), and to assess the clinical and radiological outcomes.
Our study included 90 patients who underwent prepuncture ultrasound examination of the inguinal area for TFCA between April 2015 and June 2015. Prior to skin preparation and draping of the inguinal area, we identified the CFA and its bifurcation using ultrasound. Based on the ultrasound findings, we marked cruciate lines in the inguinal area. Thereafter, we inserted a puncture needle at the interface between the horizontal and vertical lines at a 30-45° angle, simultaneously palpating the pulsation of the femoral artery. After TFCA was completed, femoral artery angiography was performed in the anteroposterior and oblique directions. Clinical and radiological parameters, including CFA cannulation, the ultrasound scan time, the first pass success rate, the time required for the passage of the wire, and complications, were evaluated.
The mean ultrasound scan time of the CFA and its bifurcation was 72.6 seconds, and the mean time between administration of local anesthesia and wire passage was 67.44 seconds. The first pass success rate was 77.8% (70/90 patients), and the CFA puncture rate was 98.8% (89/90 patients). Although minor complications were noted in 7 patients, no patient reported serious complications (a large hematoma [≥ 5 cm], pseudoaneurysms, dissection, and/or a retroperitoneal hematoma.).
Prepuncture ultrasound examination might be a simple, safe, and accurate technique for cannulation of the CFA during TFCA.
我们旨在介绍在经股动脉脑血管造影术(TFCA)期间用于股总动脉(CFA)插管的穿刺前超声扫描方法,并评估临床和影像学结果。
我们的研究纳入了2015年4月至2015年6月期间因TFCA接受腹股沟区穿刺前超声检查的90例患者。在腹股沟区皮肤准备和铺巾之前,我们使用超声识别CFA及其分叉。根据超声检查结果,我们在腹股沟区标记十字线。此后,我们以30 - 45°角在横线和纵线的交界处插入穿刺针,同时触诊股动脉搏动。TFCA完成后,在前后位和斜位进行股动脉血管造影。评估临床和影像学参数,包括CFA插管、超声扫描时间、首次穿刺成功率、导丝通过所需时间以及并发症。
CFA及其分叉的平均超声扫描时间为72.6秒,局部麻醉给药至导丝通过的平均时间为67.44秒。首次穿刺成功率为77.8%(70/90例患者),CFA穿刺率为98.8%(89/90例患者)。虽然7例患者出现轻微并发症,但无患者报告严重并发症(大血肿[≥5 cm]、假性动脉瘤、夹层和/或腹膜后血肿)。
穿刺前超声检查可能是TFCA期间CFA插管的一种简单、安全且准确的技术。
