Finney Karen N, Szuhánszki János, Darvell Leilani I, Dooley Benjamin, Milkowski Kris, Jones Jenny M, Pourkashanian Mohamed
Energy 2050, Department of Mechanical Engineering, University of Sheffield, Sheffield S3 7RD, UK.
School of Chemical and Process Engineering, Faculty of Engineering, University of Leeds, Leeds LS2 9JT, UK.
Materials (Basel). 2018 Sep 25;11(10):1819. doi: 10.3390/ma11101819.
Biomass energy with CO₂ capture could achieve net negative emissions, vital for meeting carbon budgets and emission targets. However, biomass often has significant quantities of light metals/inorganics that cause issues for boiler operation and downstream processes; including deposition, corrosion, and solvent degradation. This study investigated the pilot-scale combustion of a typical biomass used for power generation (white wood) and assessed the variations in metal aerosol release compared to bituminous coal. Using inductively coupled plasma optical emission spectrometry, it was found that K aerosol levels were significantly greater for biomass than coal, on average 6.5 times, with peaks up to 10 times higher; deposition could thus be more problematic, although Na emissions were only 20% of those for coal. Transition metals were notably less prevalent in the biomass flue gas; with Fe and V release in particular much lower (3⁻4% of those for coal). Solvent degradation may therefore be less severe for biomass-generated flue gases. Furthermore, aerosol emissions of toxic/heavy metals (As/Cd/Hg) were absent from biomass combustion, with As/Cd also not detected in the coal flue gas. Negligible Cr aerosol concentrations were found for both. Overall, except for K, metal aerosol release from biomass combustion was considerably reduced compared to coal.
具有二氧化碳捕集功能的生物质能可实现净负排放,这对实现碳预算和排放目标至关重要。然而,生物质通常含有大量轻金属/无机物,会给锅炉运行和下游工艺带来问题,包括积灰、腐蚀和溶剂降解。本研究调查了一种用于发电的典型生物质(白木)的中试规模燃烧情况,并评估了与烟煤相比金属气溶胶释放的变化。使用电感耦合等离子体发射光谱法发现,生物质的钾气溶胶水平显著高于煤炭,平均高出6.5倍,峰值高出10倍;因此积灰问题可能更严重,不过钠排放量仅为煤炭的20%。生物质烟气中过渡金属的含量明显较低;特别是铁和钒的释放量要低得多(为煤炭的3%-4%)。因此,生物质产生的烟气对溶剂的降解作用可能没那么严重。此外,生物质燃烧过程中没有产生有毒/重金属(砷/镉/汞)气溶胶排放,煤烟气中也未检测到砷/镉。两者的铬气溶胶浓度均可忽略不计。总体而言,除钾之外,生物质燃烧产生的金属气溶胶释放量与煤炭相比大幅减少。
