Relationship between Injection Rate and Contrast Enhancement on Three-dimensional Digital Subtraction Angiography of the Cerebral Arteries.

OBJECTIVE

Three-dimensional (3D) digital subtraction angiography (DSA) is becoming a common technique for the assessment of the cerebral arteries. Nevertheless, the injection parameters for each artery are not standardized among institutions. The objective of this study was to analyze the relationship between injection rate and contrast enhancement on 3D DSA of the common carotid artery.

MATERIALS AND METHODS

Twenty-four patients who underwent 3D DSA of the common carotid artery from June 2013 to March 2015 were included in this retrospective study. Contrast enhancement of each patient was analyzed for four cerebral arteries segments (A1, A2, M1 and M2) by measuring the average pixel value on the source rotational two-dimensional DSA images. Linear regression analysis was used to investigate the correlation between injection rate and contrast enhancement.

RESULTS

All four regression lines showed that a higher injection rate led to higher contrast enhancement. There was a significant relationship for the A1, A2 and M1 segments (P = 0.008, 0.03 and < 0.001) but not for the M2 segment (P = 0.13). The goodness-of-fit of the regression lines was high for the M1 segment (R = 0.63). However, as the size of the vascular lumen became narrower, the value for the A1 (R = 0.28) and A2 (R = 0.19) segments became lower.

CONCLUSION

In 3D DSA of the common carotid artery, contrast enhancement of a relatively wide lumen could be optimized by adjusting the injection rate. However, it is difficult to optimize the contrast enhancement of a relatively narrow lumen only by adjusting the injection rate.
