Owczarz Piotr, Ziółkowski Patryk, Dziubiński Marek
Department of Chemical Engineering, Lodz University of Technology, 90-924 Lodz, Poland.
Polymers (Basel). 2018 Apr 13;10(4):431. doi: 10.3390/polym10040431.
In the recent studies on chitosan hydrogels, it was found that understanding both rheological and structural properties plays an important role in their application. Therefore, a combination of two independent techniques was applied to investigate micro- and macroscopic properties of chitosan colloidal system. Studies on viscous properties, as well as the sol-gel phase transition process, were performed using rheological methods coupled with the small angle light scattering (SALS) technique. Based on the anisotropy of scattering patterns obtained during rotational shear tests, it was found that the chitosan solution reveals two different behaviors delimited by the critical value of the shear rate. Below a critical value, chitosan clusters are deformed without breaking up aggregates, whereas after exceeding a critical value, chitosan clusters apart from deformation also breakup into smaller aggregates. The values of the radius of gyration determined by applying the Debye function allow one to state that with an increase of chitosan concentration, molecule size decreases. An analysis of the light scattering data from the temperature ramp test showed that with an increase of temperature, the level of polymer coil swelling increases. Simultaneously, the supply of thermal energy leads to a neutralization of the charge of chitosan chains. As a consequence, the formation of intermolecular links occurs and a gel structure is formed.
在最近关于壳聚糖水凝胶的研究中发现,了解流变学和结构特性对其应用起着重要作用。因此,采用两种独立技术相结合的方法来研究壳聚糖胶体体系的微观和宏观性质。使用流变学方法结合小角光散射(SALS)技术对流变特性以及溶胶 - 凝胶相变过程进行了研究。基于旋转剪切试验中获得的散射图案的各向异性,发现壳聚糖溶液呈现出由剪切速率临界值界定的两种不同行为。在临界值以下,壳聚糖簇变形但聚集体不破裂,而超过临界值后,壳聚糖簇除了变形外还会分解成更小的聚集体。应用德拜函数确定的回转半径值表明,随着壳聚糖浓度的增加,分子尺寸减小。对温度斜坡试验的光散射数据分析表明,随着温度升高,聚合物线圈的溶胀程度增加。同时,热能的供应导致壳聚糖链电荷中和。结果,分子间连接形成,凝胶结构形成。
