Pooch Fabian, Sliepen Marjolein, Knudsen Kenneth D, Nyström Bo, Tenhu Heikki, Winnik Françoise M
Department of Chemistry, University of Helsinki, P.O. Box 55, Helsinki 00014, Finland.
Department of Physics, Institute for Energy Technology, P.O. Box 40, N-2027 Kjeller, Norway.
Macromolecules. 2019 Feb 12;52(3):1317-1326. doi: 10.1021/acs.macromol.8b02558. Epub 2019 Feb 1.
Poly(2-isopropyl-2-oxazoline)--poly(lactide) (PiPOx--PLA) diblock copolymers comprise two miscible blocks: the hydrophilic and thermosensitive PiPOx and the hydrophobic PLA, a biocompatible and biodegradable polyester. They self-assemble in water, forming stable dispersions of nanoparticles with hydrodynamic radii ( ) ranging from ∼18 to 60 nm, depending on their molar mass, the relative size of the two blocks, and the configuration of the lactide unit. Evidence from H nuclear magnetic resonance spectroscopy, light scattering, small-angle neutron scattering, and cryo-transmission electron microscopy indicates that the nanoparticles do not adopt the typical core-shell morphology. Aqueous nanoparticle dispersions heated from 20 to 80 °C were monitored by turbidimetry and microcalorimetry. Nanoparticles of copolymers containing a poly(dl-lactide) block coagulated irreversibly upon heating to 50 °C, forming particles of various shapes ( ∼ 200-500 nm). Dispersions of PiPOx--poly(l-lactide) coagulated to a lesser extent or remained stable upon heating. From the entire experimental evidence, we conclude that PiPOx--PLA nanoparticles consist of a core of PLA/PiPOx chains associated via dipole-dipole interactions of the PLA and PiPOx carbonyl groups. The core is surrounded by tethered PiPOx loops and tails responsible for the colloidal stability of the nanoparticles in water. While the core of all nanoparticles studied contains associated PiPOx and PLA blocks, fine details of the nanoparticles morphology vary predictably with the size and composition of the copolymers, yielding particles of distinctive thermosensitivity in aqueous dispersions.
聚(2-异丙基-2-恶唑啉)-聚(丙交酯)(PiPOx-PLA)二嵌段共聚物由两个可混溶的嵌段组成:亲水性且具有热敏性的PiPOx和疏水性的PLA(一种生物相容性和可生物降解的聚酯)。它们在水中自组装,形成水动力学半径( )范围约为18至60nm的稳定纳米颗粒分散体,这取决于它们的摩尔质量、两个嵌段的相对尺寸以及丙交酯单元的构型。来自氢核磁共振光谱、光散射、小角中子散射和低温透射电子显微镜的证据表明,纳米颗粒不具有典型的核壳形态。通过比浊法和微量量热法监测从20℃加热到80℃的水性纳米颗粒分散体。含有聚(dl-丙交酯)嵌段的共聚物纳米颗粒在加热到50℃时不可逆地凝聚,形成各种形状( 约200-500nm)的颗粒。PiPOx-聚(l-丙交酯)的分散体在加热时凝聚程度较小或保持稳定。从整个实验证据来看,我们得出结论,PiPOx-PLA纳米颗粒由通过PLA和PiPOx羰基的偶极-偶极相互作用缔合的PLA/PiPOx链的核组成。核被负责纳米颗粒在水中胶体稳定性的连接的PiPOx环和尾巴包围。虽然所有研究的纳米颗粒的核都含有缔合的PiPOx和PLA嵌段,但纳米颗粒形态的细微细节随共聚物的尺寸和组成可预测地变化,在水性分散体中产生具有独特热敏性的颗粒。
