Wellcome Centre for Integrative Neuroimaging, FMRIB Centre, John Radcliffe Hospital, University of Oxford, OX3 9DU, Headington, Oxford, UK.
Department of Neurosurgery, John Radcliffe Hospital, Oxford University Hospitals NHS Foundation Trust, Oxford, UK.
Clin Neuroradiol. 2021 Mar;31(1):245-256. doi: 10.1007/s00062-020-00879-1. Epub 2020 Apr 9.
Functional magnetic resonance imaging (fMRI) has an established role in neurosurgical planning; however, ambiguity surrounds the comparative value of resting and task-based fMRI relative to anatomical localization of the sensorimotor cortex. This study was carried out to determine: 1) how often fMRI adds to prediction of motor risks beyond expert neuroradiological review, 2) success rates of presurgical resting and task-based sensorimotor mapping, and 3) the impact of accelerated resting fMRI acquisitions on network detectability.
Data were collected at 2 centers from 71 patients with a primary brain tumor (31 women; mean age 41.9 ± 13.9 years) and 14 healthy individuals (6 women; mean age 37.9 ± 12.7 years). Preoperative 3T MRI included anatomical scans and resting fMRI using unaccelerated (TR = 3.5 s), intermediate (TR = 1.56 s) or high temporal resolution (TR = 0.72 s) sequences. Task fMRI finger tapping data were acquired in 45 patients. Group differences in fMRI reproducibility, spatial overlap and success frequencies were assessed with t‑tests and χ-tests.
Radiological review identified the central sulcus in 98.6% (70/71) patients. Task-fMRI succeeded in 100% (45/45). Resting fMRI failed to identify a sensorimotor network in up to 10 patients; it succeeded in 97.9% (47/48) of accelerated fMRIs, compared to only 60.9% (14/23) of unaccelerated fMRIs (Formula: see text = 17.84, p < 0.001). Of the patients 12 experienced postoperative deterioration, largely predicted by anatomical proximity to the central sulcus.
The use of fMRI in patients with residual or intact presurgical motor function added value to uncertain anatomical localization in just a single peri-Rolandic glioma case. Resting fMRI showed high correspondence to task localization when acquired with accelerated sequences but offered limited success at standard acquisitions.
功能磁共振成像(fMRI)在神经外科规划中具有既定的作用;然而,相对于感觉运动皮层的解剖定位,静息态和任务态 fMRI 的相对价值仍存在争议。本研究旨在确定:1)fMRI 在多大程度上可以增加对运动风险的预测,超出专家神经放射学评估的范围;2)术前静息和任务感觉运动映射的成功率;3)加速静息 fMRI 采集对网络可检测性的影响。
本研究在两个中心共收集了 71 例原发性脑肿瘤患者(31 名女性;平均年龄 41.9±13.9 岁)和 14 名健康个体(6 名女性;平均年龄 37.9±12.7 岁)的数据。术前 3T MRI 包括解剖扫描和使用未加速(TR=3.5s)、中等(TR=1.56s)或高时间分辨率(TR=0.72s)序列的静息 fMRI。45 例患者采集了任务 fMRI 手指敲击数据。采用 t 检验和 χ 检验评估 fMRI 可重复性、空间重叠和成功率的组间差异。
放射学评估在 98.6%(70/71)的患者中识别出中央沟。任务 fMRI 在 100%(45/45)的患者中成功。多达 10 例患者的静息 fMRI 未能识别出感觉运动网络;在加速 fMRI 中成功率为 97.9%(47/48),而在未加速 fMRI 中成功率仅为 60.9%(14/23)(Formula: see text=17.84,p<0.001)。12 例患者术后出现恶化,主要与中央沟附近的解剖位置有关。
在有残留或完整术前运动功能的患者中使用 fMRI,为单一靠近 Roland 区胶质瘤病例中不确定的解剖定位增加了价值。当使用加速序列采集时,静息 fMRI 与任务定位具有高度一致性,但在标准采集时成功率有限。
