心脏磁共振成像与血流储备分数的诊断准确性:一项系统评价与荟萃分析

Diagnostic Accuracy of Cardiac Magnetic Resonance Versus Fractional Flow Reserve: A Systematic Review and Meta-Analysis.

作者信息

Ullah Waqas, Roomi Sohaib, Abdullah Hafez M, Mukhtar Maryam, Ali Zain, Ye Ping, Haas Donald C, Figueredo Vincent M

机构信息

Internal Medicine, Abington Hospital-Jefferson Health, Abington, PA, USA.

Internal Medicine, University of South Dakota, Sioux Falls, SD, USA.

出版信息

Cardiol Res. 2020 Jun;11(3):145-154. doi: 10.14740/cr1028. Epub 2020 May 3.

DOI:10.14740/cr1028
PMID:32494324
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC7239594/
Abstract

BACKGROUND

Fractional flow reserve (FFR) is considered the gold standard for diagnosis of coronary artery disease (CAD). Stress Cardiac magnetic resonance (SCMR) has been recently gaining traction as a non-invasive alternative to FFR.

METHODS

Studies comparing the diagnostic accuracy of SCMR versus FFR were identified and analyzed using Review Manager (RevMan) 5.3 and Stata software.

RESULTS

A total of 28 studies, comprising 2,387 patients, were included. The pooled sensitivity and specificity for SCMR were 86% and 86% at the patient level, and 82% and 88% at the vessel level, respectively. When the patient-level data were stratified based on the FFR thresholds, higher sensitivity and specificity (both 90%) were noted with the higher cutoff (0.75) and lower cutoff (0.8), respectively. At the vessel level, sensitivity and specificity at the lower FFR threshold were significantly higher at 88% and 89%, compared to the corresponding values for higher cutoff at 0.75. Similarly, meta-regression analysis of SCMR at higher (3T) resolution showed a higher sensitivity of 87% at the patient level and higher specificity of 90% at the vessel level. The highest sensitivity and specificity of SCMR (92% and 94%, respectively) were noted in studies with CAD prevalence greater than 60%.

CONCLUSIONS

SCMR has high diagnostic accuracy for CAD comparable to FFR at a spatial resolution of 3T and an FFR cut-off of 0.80. An increase in CAD prevalence further improved the specificity of SCMR.

摘要

背景

血流储备分数(FFR)被认为是冠状动脉疾病(CAD)诊断的金标准。应力心脏磁共振成像(SCMR)作为FFR的一种非侵入性替代方法,近来越来越受到关注。

方法

使用Review Manager(RevMan)5.3和Stata软件识别并分析比较SCMR与FFR诊断准确性的研究。

结果

共纳入28项研究,包括2387例患者。在患者层面,SCMR的合并敏感性和特异性分别为86%和86%,在血管层面分别为82%和88%。当根据FFR阈值对患者层面的数据进行分层时,较高的临界值(0.75)和较低的临界值(0.8)分别显示出更高的敏感性和特异性(均为90%)。在血管层面,较低FFR阈值时的敏感性和特异性分别为88%和89%,显著高于0.75较高临界值时的相应值。同样,对更高(3T)分辨率的SCMR进行的Meta回归分析显示,在患者层面敏感性更高,为87%,在血管层面特异性更高,为90%。在CAD患病率大于60%的研究中,SCMR的敏感性和特异性最高(分别为92%和94%)。

结论

在3T空间分辨率和FFR临界值为0.80时,SCMR对CAD具有与FFR相当的高诊断准确性。CAD患病率的增加进一步提高了SCMR的特异性。
