术中无影像导航(Naviswiss)在初次全髋关节置换术中组件定位准确性的有效性:单外科医生实践中的前瞻性观察队列研究方案

Validity of intraoperative imageless navigation (Naviswiss) for component positioning accuracy in primary total hip arthroplasty: protocol for a prospective observational cohort study in a single-surgeon practice.

作者信息

Ektas Nalan, Scholes Corey, Ruiz Alejandro M, Ireland John

机构信息

EBM Analytics, Sydney, New South Wales, Australia.

EBM Analytics, Sydney, New South Wales, Australia

出版信息

BMJ Open. 2020 Oct 5;10(10):e037126. doi: 10.1136/bmjopen-2020-037126.

DOI:10.1136/bmjopen-2020-037126
PMID:33020091
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC7537456/
Abstract

INTRODUCTION

Optimal outcomes in total hip arthroplasty (THA) are dependent on appropriate placement of femoral and acetabular components, with technological advances providing a platform for guiding component placement to reduce the risk of malpositioned components during surgery. This study will validate the intraoperative data captured using a handheld imageless THA navigation system against postoperative measurements of acetabular inclination, acetabular version, leg length and femoral offset on CT radiographs.

METHODS AND ANALYSIS

This is a prospective observational cohort study conducted within a single-centre, single-surgeon private practice. Data will be collected for 35 consecutive patients (>18 years) undergoing elective THA surgery, from the research registry established at the surgeon's practice. The primary outcome is the agreement between intraoperative component positioning data captured by the navigation system compared with postoperative measurements using CT. A total of ten CT scans will be reassessed for interobserver and intraobserver reliability. The influence of patient and surgical factors on the accuracy of component position will also be examined with multivariable linear regression.

ETHICS AND DISSEMINATION

Ethics approval for this study was provided through a certified ethics committee (Bellberry HREC approval number 2017-07-499). The results of this study will be disseminated through peer-reviewed journals and conference presentations.

TRIAL REGISTRATION

Australian and New Zealand Clinical Trials Registry (ANZCTR) Trial ID: ACTRN12620000089932.

摘要

引言

全髋关节置换术(THA)的最佳疗效取决于股骨和髋臼组件的正确放置,技术进步为引导组件放置提供了一个平台,以降低手术过程中组件放置不当的风险。本研究将对照CTX光片上髋臼倾斜度、髋臼旋转、腿长和股骨偏移的术后测量值,验证使用手持式无影像THA导航系统捕获的术中数据。

方法与分析

这是一项在单中心、单外科医生私人诊所进行的前瞻性观察队列研究。将从外科医生诊所建立的研究登记处收集35例连续接受择期THA手术的患者(>18岁)的数据。主要结果是导航系统捕获的术中组件定位数据与使用CT的术后测量值之间的一致性。将重新评估总共十次CT扫描的观察者间和观察者内可靠性。还将通过多变量线性回归检查患者和手术因素对组件位置准确性的影响。

伦理与传播

本研究已通过认证伦理委员会获得伦理批准(Bellberry HREC批准号2017 - 07 - 499)。本研究结果将通过同行评审期刊和会议报告进行传播。

试验注册

澳大利亚和新西兰临床试验注册中心(ANZCTR)试验编号:ACTRN12620000089932。
