Department of Ultrasound in Medicine, Shanghai Jiaotong University Affiliated Sixth People's Hospital, Shanghai Institute of Ultrasound in Medicine, Shanghai, China.
Sci Rep. 2020 Oct 20;10(1):17848. doi: 10.1038/s41598-020-74774-7.
To evaluate the imaging features of subungual glomus tumors using 18 MHz high-frequency ultrasound with CDFI (Color Doppler Flow Imaging). 20 patients treated by surgical resection and examined by ultrasound between January 2008 and December 2019. All eligible cases are divided into two groups: Group A used the probe frequency of 9-14 MHz from January 2008 to December 2014, and Group B used the probe frequency of 18 MHz from January 2015 to December 2019. Patient demographics, clinical records, pathologic specimens and sonography features were reviewed. 50% of tumors in Group A and 100% of tumors in Group B showed clear boundary and regular shape. Blood flow signals were identified inside 50% tumors in Group A (3 in 6), all 14 cases with blood flow signals detected in Group B (14 in 14,100%). 2 cases were misdiagnosed and 1 case escaped diagnosis in Group A, no case was misdiagnosed in Group B. The accuracy of diagnosis rate of Group B is significantly higher than that of Group A. 18-MHz ultrasound combined with CDFI may be a practical useful tool for detecting subungual glomus tumors. More importantly 18-MHz ultrasound can obviously improve the diagnostic accuracy.
采用 18MHz 高频超声联合 CDFI(彩色多普勒血流成像)评估甲下血管球瘤的影像学特征。20 例患者经手术切除治疗,于 2008 年 1 月至 2019 年 12 月接受超声检查。所有符合条件的病例分为两组:A 组采用 2008 年 1 月至 2014 年 12 月探头频率为 9-14MHz,B 组采用 2015 年 1 月至 2019 年 12 月探头频率为 18MHz。回顾患者的人口统计学资料、临床记录、病理标本和超声特征。A 组 50%的肿瘤边界清晰,形状规则,B 组 100%的肿瘤边界清晰,形状规则。A 组 50%(3/6)的肿瘤内可见血流信号,B 组 14 例(14/14,100%)均可见血流信号。A 组有 2 例误诊,1 例漏诊,B 组无一例误诊。B 组的诊断准确率明显高于 A 组。18MHz 超声联合 CDFI 可能是一种实用的检测甲下血管球瘤的方法。更重要的是,18MHz 超声可以明显提高诊断准确率。
