Mauro Nicolò, Utzeri Mara Andrea, Buscarino Gianpiero, Sciortino Alice, Messina Fabrizio, Cavallaro Gennara, Giammona Gaetano
Laboratory of Biocompatible Polymers, Department of Biological, Chemical and Pharmaceutical Sciences and Technologies, University of Palermo, via Archirafi 32, 90123 Palermo, Italy.
Fondazione Umberto Veronesi, Piazza Velasca 5, 20122 Milano, Italy.
Materials (Basel). 2020 Oct 31;13(21):4899. doi: 10.3390/ma13214899.
Carbon nanodots (CDs) have recently attracted attention in the field of nanomedicine because of the biocompatibility, cost-effective nature, high specific surface, good near infrared (NIR) photothermal conversion into heat and tunable fluorescence properties, which have paved the way toward incorporating use of CDs into innovative anticancer theranostic platforms. However, a reliable synthesis of CDs with established and controlled physiochemical proprieties is precluded owing to the lack of full manipulation of thermodynamic parameters during the synthesis, thus limiting their use in real world medical applications. Herein, we developed a robust solvothermal protocol which allow fine controlling of temperature and pressure in order to obtain CDs with tunable properties. We obtained different CDs by modulating the operating pressure (from 8 to 18.5 bar) during the solvothermal decomposition of urea and citric acid in N,N-dimethylformamide at fixed composition. Atomic force microscopy (AFM), Fourier transform infrared (FTIR), ultraviolet-visible (UV-vis) and fluorescence spectroscopy were used to assess the role of pressure in influencing size, optical and surface properties of the obtained CDs. While preliminary biological and anticancer performance of CDs was established on the MDA-MB-231 cell line, used as triple negative breast cancer model. Our results indicate that pressure impinge on the formation of carbon nanoparticles under solvothermal conditions and impart desired optical, size distribution, surface functionalization and anticancer properties in a facile way. However, we have highlighted that a strategic surface engineering of these CDs is needed to limit the adsorption of corona proteins and also to increase the average surface diameter, avoiding a rapid renal clearance and improving their therapeutic efficacy in vivo.
碳纳米点(CDs)因其生物相容性、成本效益高、比表面积大、良好的近红外(NIR)光热转化为热以及可调谐荧光特性,最近在纳米医学领域引起了关注,这些特性为将CDs纳入创新的抗癌诊疗平台铺平了道路。然而,由于在合成过程中缺乏对热力学参数的完全控制,无法可靠地合成具有既定和可控物理化学性质的CDs,从而限制了它们在实际医学应用中的使用。在此,我们开发了一种强大的溶剂热方法,该方法允许精确控制温度和压力,以获得具有可调谐特性的CDs。我们通过在固定组成的N,N-二甲基甲酰胺中尿素和柠檬酸的溶剂热分解过程中调节操作压力(从8到18.5巴)获得了不同的CDs。使用原子力显微镜(AFM)、傅里叶变换红外光谱(FTIR)、紫外可见光谱(UV-vis)和荧光光谱来评估压力对所得CDs的尺寸、光学和表面性质的影响。同时,在用作三阴性乳腺癌模型的MDA-MB-231细胞系上建立了CDs的初步生物学和抗癌性能。我们的结果表明,压力在溶剂热条件下影响碳纳米颗粒的形成,并以简便的方式赋予所需的光学、尺寸分布、表面功能化和抗癌特性。然而,我们强调需要对这些CDs进行战略性的表面工程,以限制冠状蛋白的吸附,并增加平均表面直径,避免快速肾清除并提高其体内治疗效果。
