BACKGROUND: The influence of pedicle screw number and insertion depth on outcomes of lumbar fixation remains uncertain. The purpose of this study was to compare the imaging balance stability and clinical functional improvement of lumbar fracture patients with different pedicle screw numbers and insertion depths. METHODS: Sixty-five patients undergoing lumbar pedicle screw fixation from January 2016 to January 2018 were enrolled. They were included in long screw (LS) group and short screw (SS) group or 6 screw (6S) group and 4 screw (4S) group. The radiographic outcomes were assessed with lumbar lordosis (LL), segmental lordosis (SL), fractured vertebral lordosis (FL), sacral slope (SS), pelvic incidence (PL), and pelvic tilt (PT). The visual analog scale (VAS) and the Oswestry Disability Index (ODI) score were used for functional assessment. Multiple linear regression was performed to identify the risk factors of FL, SL, and LL correction at the final follow-up. RESULTS: FL, SL, and LL were significantly different in all matching subgroups to compare long and short screws and in most matching subgroups to compare 6 and 4 screws. The SS, PT, and PI seem to be similar in all subgroups in different periods. Significant differences of VAS and ODI were found between LS and SS in the 4S group and between 4S and 6S in the SS group. Insertion depth, screw number, BMD, age, and preoperative imaging data were significant factors for imaging balance stability correction at the final follow-up. CONCLUSIONS: Long screws and 6 screws showed better fracture vertebral restoration and lumbar spinal sagittal stabilities. The surgery type, age, and BMD are important focus points for the treatment of lumbar vertebral fractures.
