On local intrinsic dimensionality of deformation in complex materials.

We propose a new metric called s-LID based on the concept of Local Intrinsic Dimensionality to identify and quantify hierarchies of kinematic patterns in heterogeneous media. s-LID measures how outlying a grain's motion is relative to its s nearest neighbors in displacement state space. To demonstrate the merits of s-LID over the conventional measure of strain, we apply it to data on individual grain motions in a set of deforming granular materials. Several new insights into the evolution of failure are uncovered. First, s-LID reveals a hierarchy of concurrent deformation bands that prevails throughout loading history. These structures vary not only in relative dominance but also spatial and kinematic scales. Second, in the nascent stages of the pre-failure regime, s-LID uncovers a set of system-spanning, criss-crossing bands: microbands for small s and embryonic-shearbands at large s, with the former being dominant. At the opposite extreme, in the failure regime, fully formed shearbands at large s dominate over the microbands. The novel patterns uncovered from s-LID contradict the common belief of a causal sequence where a subset of microbands coalesce and/or grow to form shearbands. Instead, s-LID suggests that the deformation of the sample in the lead-up to failure is governed by a complex symbiosis among these different coexisting structures, which amplifies and promotes the progressive dominance of the embryonic-shearbands over microbands. Third, we probed this transition from the microband-dominated regime to the shearband-dominated regime by systematically suppressing grain rotations. We found particle rotation to be an essential enabler of the transition to the shearband-dominated regime. When grain rotations are completely suppressed, this transition is prevented: microbands and shearbands coexist in relative parity.
