IEEE Trans Neural Syst Rehabil Eng. 2021;29:2067-2075. doi: 10.1109/TNSRE.2021.3117518. Epub 2021 Oct 13.
Continuous sacral neuromodulation (SNM) is used to treat overactive bladder, reducing urine leakage and increasing capacity. Conditional SNM applies stimulation in response to changing bladder conditions, and is an opportunity to study neuromodulation effects in various disease states. A key advantage of this approach is saving power consumed by stimulation pulses. This study demonstrated feasibility of automatically applying neuromodulation using a wireless bladder pressure sensor, a real-time control algorithm, and the Medtronic Summit RC+S neurostimulation research system. This study tested feasibility of four conditional SNM paradigms over five days in 4 female sheep. Primary outcomes assessed proof of concept of closed-loop system function. While the bladder pressure sensor correlated only weakly to simultaneous catheter-based pressure measurement (correlation 0.26-0.89, median r = 0.52), the sensor and algorithm were accurate enough to automatically trigger SNM appropriately. The neurostimulator executed 98.5% of transmitted stimulation commands with a median latency of 72 ms (n = 1,206), suggesting that rapid decision-making and control is feasible with this platform. On average, bladder capacity increased for continuous SNM and algorithm-controlled paradigms. Some animals responded more strongly to conditional SNM, suggesting that treatment could be individualized. Future research in conditional SNM may elucidate the physiologic underpinnings of differential response and enable clinical translation.
持续骶神经调节(SNM)用于治疗过度活跃的膀胱,减少尿漏并增加容量。条件性 SNM 根据膀胱状况的变化施加刺激,是研究各种疾病状态下神经调节作用的机会。这种方法的一个主要优点是节省刺激脉冲消耗的能量。本研究使用无线膀胱压力传感器、实时控制算法和 Medtronic Summit RC+S 神经刺激研究系统,展示了使用自动神经调节的可行性。本研究在 4 只雌性绵羊中进行了为期 5 天的 4 种条件性 SNM 模式的可行性测试。主要结果评估了闭环系统功能的概念验证。虽然膀胱压力传感器与同时进行的基于导管的压力测量相关性较弱(相关性 0.26-0.89,中位数 r = 0.52),但传感器和算法足以准确地自动触发 SNM。神经刺激器以 72 毫秒的中位数延迟执行了 98.5%的传输刺激命令(n = 1,206),这表明使用该平台可以实现快速决策和控制。平均而言,连续 SNM 和算法控制的模式下膀胱容量增加。一些动物对条件性 SNM 的反应更强烈,这表明可以对治疗进行个体化。条件性 SNM 的未来研究可能阐明差异反应的生理基础,并实现临床转化。
