A Review of Human Circulatory System Simulation: Bridging the Gap between Engineering and Medicine.

(1) Background: Simulation-based training (SBT) is the practice of using hands-on training to immerse learners in a risk-free and high-fidelity environment. SBT is used in various fields due to its risk-free benefits from a safety and an economic perspective. In addition, SBT provides immersive training unmatched by traditional teaching the interactive visualization needed in particular scenarios. Medical SBT is a prevalent practice as it allows for a platform for learners to learn in a risk-free and cost-effective environment, especially in critical care, as mistakes could easily cause fatalities. An essential category of care is human circulatory system care (HCSC), which includes essential-to-simulate complications such as cardiac arrest. (2) Methods: In this paper, a deeper look onto existing human circulatory system medical SBT is presented to assess and highlight the important features that should be present with a focus on extracorporeal membrane oxygenation cannulation (ECMO) simulators and cardiac catheterization. (3) Results: A list of features is also suggested for an ideal simulator to bridge the gap between medical studies and simulator engineering, followed by a case study of an ECMO SBT system design. (4) Conclusions: a collection and discussion of existing work for HCSC SBT are portrayed as a guide for researchers and practitioners to compare existing SBT and recreating them effectively.
