用于单光子雪崩二极管 (SPAD) 传感应用的磁性碳纳米纤维垫。

Magnetic Carbon Nanofiber Mats for Prospective Single Photon Avalanche Diode (SPAD) Sensing Applications.

机构信息

Ecole Nationale d'Ingénieurs de Sfax, Laboratory LGME, University of Sfax, Sfax 3038, Tunisia.

Junior Research Group "Nanomaterials", Faculty of Engineering and Mathematics, Bielefeld University of Applied Sciences, 33619 Bielefeld, Germany.

出版信息

Sensors (Basel). 2021 Nov 26;21(23):7873. doi: 10.3390/s21237873.

DOI:10.3390/s21237873
PMID:34883875
原文链接:https://pmc.ncbi.nlm.nih.gov/articles/PMC8659674/
Abstract

Electrospinning enables simple and cost-effective production of magnetic nanofibers by adding nanoparticles to a polymer solution. In order to increase the electrical conductivity of such nanofibers, the carbonization process is crucial. In this study, the chemical and morphological properties of magnetic nanofiber mats prepared from polyacrylonitrile (PAN)/magnetite were investigated. In our previous studies, PAN/magnetite nanofiber mats were carbonized at 500 °C, 600 °C, and 800 °C. Here, PAN/magnetite nanofiber mats were carbonized at 1000 °C. The surface morphology of these PAN/magnetite nanofiber mats is not significantly different from nanofiber mats thermally treated at 800 °C and have remained relatively flexible at 1000 °C, which can be advantageous for various application fields. The addition of nanoparticles increased the average fiber diameter compared to pure PAN nanofiber mats and improved the dimensional stability during thermal processes. The high conductivity, the high magnetization properties, as well as shielding against electromagnetic interference of such carbonized nanofibers can be proposed for use in single photon avalanche diode (SPAD), where these properties are advantageous.

摘要

静电纺丝通过向聚合物溶液中添加纳米颗粒，实现了磁性纳米纤维的简单且经济高效的生产。为了提高这种纳米纤维的导电性，碳化过程至关重要。在这项研究中，研究了由聚丙烯腈 (PAN)/磁铁矿制备的磁性纳米纤维垫的化学和形态特性。在我们之前的研究中，PAN/磁铁矿纳米纤维垫在 500°C、600°C 和 800°C 下碳化。在这里，PAN/磁铁矿纳米纤维垫在 1000°C 下碳化。这些 PAN/磁铁矿纳米纤维垫的表面形貌与在 800°C 下热处理的纳米纤维垫没有明显区别，并且在 1000°C 下仍然保持相对柔韧性，这对于各种应用领域可能是有利的。与纯 PAN 纳米纤维垫相比，纳米颗粒的添加增加了平均纤维直径，并提高了热过程中的尺寸稳定性。这种碳化纳米纤维的高导电性、高磁化性能以及对电磁干扰的屏蔽作用，可以用于单光子雪崩二极管 (SPAD)，这些性质在其中具有优势。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/0e5338f477a7/sensors-21-07873-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d73c18dccce6/sensors-21-07873-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/6cd421673045/sensors-21-07873-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d9e8713f92eb/sensors-21-07873-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/5d7f163f05e2/sensors-21-07873-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/fc2d776df5be/sensors-21-07873-g005a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/b03cef38d4cb/sensors-21-07873-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d654c81ca248/sensors-21-07873-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/0983250d9255/sensors-21-07873-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/0e5338f477a7/sensors-21-07873-g009.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d73c18dccce6/sensors-21-07873-g001.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/6cd421673045/sensors-21-07873-g002.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d9e8713f92eb/sensors-21-07873-g003.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/5d7f163f05e2/sensors-21-07873-g004.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/fc2d776df5be/sensors-21-07873-g005a.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/b03cef38d4cb/sensors-21-07873-g006.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/d654c81ca248/sensors-21-07873-g007.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/0983250d9255/sensors-21-07873-g008.jpg
https://cdn.ncbi.nlm.nih.gov/pmc/blobs/5f7c/8659674/0e5338f477a7/sensors-21-07873-g009.jpg
