多源的相位相关单通道连续波多普勒雷达识别。

Phase Correlation Single Channel Continuous Wave Doppler Radar Recognition of Multiple Sources.

机构信息

Department of Electrical and Computer Engineering, University of Hawai'i at Manoa, Honolulu, HI 96822, USA.

出版信息

Sensors (Basel). 2022 Jan 26;22(3):970. doi: 10.3390/s22030970.

Abstract

Continuous-wave Doppler radar (CWDR) can be used to remotely detect physiological parameters, such as respiration and heart signals. However, detecting and separating multiple targets remains a challenging task for CWDR. While complex transceiver architectures and advanced signal processing algorithms have been demonstrated as effective for multiple target separations in some scenarios, the separation of equidistant sources within a single antenna beam remains a challenge. This paper presents an alternative phase tuning approach that exploits the diversity among target distances and physiological parameters for multi-target detection. The design utilizes a voltage-controlled analog phase shifter to manipulate the phase correlation of the CWDR and thus create different signal mixtures from the multiple targets, then separates them in the frequency domain by suppressing individual signals sequentially. We implemented the phase correlation system based on a 2.4 GHz single-channel CWDR and evaluated it against multiple mechanical and human targets. The experimental results demonstrated successful separation of nearly equidistant targets within an antenna beam, equivalent to separating physiological signals of two people seated shoulder to shoulder.

摘要

连续波多普勒雷达(CWDR)可用于远程检测生理参数,如呼吸和心跳信号。然而,对于 CWDR 来说,检测和分离多个目标仍然是一项具有挑战性的任务。虽然复杂的收发架构和先进的信号处理算法已经在某些场景中被证明可以有效地分离多个目标,但在单个天线波束内分离等距源仍然是一个挑战。本文提出了一种替代的相位调谐方法,利用目标距离和生理参数的多样性进行多目标检测。该设计利用电压控制模拟移相器来操纵 CWDR 的相位相关性,从而从多个目标中创建不同的信号混合物,然后通过依次抑制单个信号在频域中将它们分离。我们基于 2.4GHz 单通道 CWDR 实现了该相位相关系统,并针对多个机械和人体目标进行了评估。实验结果表明,成功地分离了天线波束内几乎等距的目标,相当于分离肩并肩坐着的两个人的生理信号。

https://cdn.ncbi.nlm.nih.gov/pmc/blobs/c8f9/8840519/3773bd1ca453/sensors-22-00970-g001.jpg
