经空气等离子体处理改性的高性能及防水聚乙烯醇基薄膜

High-Performance and Water Resistant PVA-Based Films Modified by Air Plasma Treatment.

作者信息

Rao Xin, Zhou Qi, Wen Qin, Ou Zhiqiang, Fu Lingying, Gong Yue, Du Xueyu, Huo Chunqing

机构信息

Hainan Provincial Fine Chemical Engineering Research Center, Hainan University, Haikou 570228, China.

Hainan Provincial Key Lab of Fine Chemistry, Hainan University, Haikou 570228, China.

出版信息

Membranes (Basel). 2022 Feb 22;12(3):249. doi: 10.3390/membranes12030249.

Abstract

Plasma treatment is considered a straightforward, cost-effective, and environmental-friendly technique for surface modification of film materials. In this study, air plasma treatment was applied for performance improvement of pure PVA, cellulose nanocrystal (CNC)/PVA, and CNC/oxalic acid (OA)/PVA films. Compared with the original performance of pure PVA, the mechanical properties and water resistance of air plasma treated films were greatly improved. Among them, the CNC/OA/PVA film treated by three minutes of air plasma irradiation exhibits the most remarkable performance in mechanical properties (tensile strength: 132.7 MPa; Young's modulus: 5379.9 MPa) and water resistance (degree of swelling: 47.5%; solubility: 6.0%). By means of various modern characterization methods, the wettability, surface chemical structure, surface roughness, and thermal stability of different films before and after air plasma treatment were further revealed. Based on the results obtained, the air plasma treatment only changed the surface chemical structure, surface roughness, and hydrophobicity, while keeping the inner structure of films intact.

摘要

等离子体处理被认为是一种用于薄膜材料表面改性的直接、经济高效且环境友好的技术。在本研究中,采用空气等离子体处理来提高纯聚乙烯醇(PVA)、纤维素纳米晶体(CNC)/PVA和CNC/草酸(OA)/PVA薄膜的性能。与纯PVA的原始性能相比,空气等离子体处理后的薄膜的机械性能和耐水性得到了极大提高。其中,经过三分钟空气等离子体辐照处理的CNC/OA/PVA薄膜在机械性能(拉伸强度:132.7兆帕;杨氏模量:5379.9兆帕)和耐水性(溶胀度:47.5%;溶解度:6.0%)方面表现出最显著的性能。通过各种现代表征方法,进一步揭示了空气等离子体处理前后不同薄膜的润湿性、表面化学结构、表面粗糙度和热稳定性。基于所获得的结果,空气等离子体处理仅改变了薄膜的表面化学结构、表面粗糙度和疏水性,而薄膜的内部结构保持完整。
