Sr sorption property of seaweed-like sodium titanate mats: effects of crystallographic properties.

Layered sodium titanate is a typical ion-exchanger for water purification aimed at removing cationic heavy metals and radionuclides. The material design of an ion-exchanger is effective for cation removal. For that purpose, understanding the basic impacts of crystallographic properties such as crystal size, morphology, and phase is critical for developing highly functional nanoscale ion-exchangers. In this study, we investigate the principal relationship between the crystallographic properties of seaweed-like sodium titanate mats (SSTs), which consist of a dititanate (H Na TiO) phase of nanofibers synthesised by the alkaline hydrothermal method and their Sr sorption mechanism. A trititanate (H Na TiO) phase, which has a micro-sized fibre morphology, was also synthesised using the same method by adjusting the NaOH concentration. The SST demonstrates a high ion-exchange selectivity of Sr against H and a high maximum sorption capacity (2 mmol g), which was four times higher than that of the trititanate phase (0.49 mmol g). In contrast, the trititanate phase, which is the comparison target, had a low Sr ion-exchange selectivity and precipitated SrCO. We conclude that these differences in Sr sorption mechanisms were derived from not only the unique morphology but also the crystal structure of sodium titanates. Although almost all of the Na in dititanate with lamellar structure was consumed by the ion-exchange reaction, some Na remained in the trititanate because there are two sites in the zigzag layered structure. These findings on the crystallographic properties of SST for Sr sorption may contribute to the functionalisation of a nanoscale ion-exchanger.
