Fan Sichen, Sun Yang, Yang Tianhua, Chen Yongsheng, Yan Beibei, Li Rundong, Chen Guanyi
School of Energy and Environment, Liaoning Province Key Laboratory of Clean Energy, Shenyang Aerospace University Shenyang 110036 China.
School of Environmental Science and Engineering, Tianjin Key Lab of Biomass Wastes Utilization, Tianjin University No. 135 Yaguan Road, Haihe Education Park, Jinnan District Tianjin 300072 China
RSC Adv. 2020 Feb 11;10(11):6362-6376. doi: 10.1039/c9ra09487c. eCollection 2020 Feb 7.
Biochar is widely used as adsorbents for gaseous or liquid pollutants due to its special pore structure. Previous studies have shown that the adsorption performance of untreated biomass pyrolysis crude carbon is poor, which can be improved by optimizing physicochemical properties such as pore structure and surface area. The study focused on the co-pyrolysis of skins, pith, and leaves with polyethylene and potassium hydroxide modification to adjust the quality of the biochar, compared with raw materials of corn stalks without separation. The physical and chemical properties of the biochar were analyzed and the adsorption effect, adsorption isotherms, and kinetics of Pb(ii) removal were investigated. Results demonstrated that co-pyrolysis of biomass and polyethylene increase the yield of biochar with an average increase of about 20%. Polyethylene brought high aromaticity, high calorific value and stable material structure to biochar. Potassium hydroxide modification increased its specific surface area and made the pore structure of biochar more uniform, mainly microporous structure. The specific surface areas of the four modified biochar were 521.07 m g, 581.85 m g, 304.99 m g, and 429.97 m g. The adsorption capacity of biochar for Pb(ii) was greatly improved with the increase of the OH functional group of biochar. The stem-pith biochar had the best adsorption effect, with an adsorption amount of 99.95 mg g and a removal efficiency of 50.35%. The Pseudo-second-order model and Langmuir adsorption isotherm model could preferably describe the adsorption process, indicating the adsorption of lead was monolayer accompanied by chemical adsorption. It can be concluded that co-pyrolysis of biomass and polyethylene and modification may be favorable to enhance the properties of biochar. In addition to syngas and bio-oil from co-pyrolysis, biochar may be a valuable by-product for commercial use, which can be used to remove heavy metals in water, especially stem-pith biochar.
生物炭因其特殊的孔隙结构而被广泛用作气态或液态污染物的吸附剂。以往研究表明,未经处理的生物质热解粗炭吸附性能较差,可通过优化孔隙结构和比表面积等物理化学性质来改善。本研究聚焦于将果皮、髓和树叶与聚乙烯共热解,并采用氢氧化钾改性以调整生物炭质量,同时与未分离的玉米秸秆原料进行对比。分析了生物炭的物理化学性质,并研究了其对Pb(ii)的吸附效果、吸附等温线及动力学。结果表明,生物质与聚乙烯共热解可提高生物炭产率,平均提高约20%。聚乙烯赋予生物炭高芳香性、高热值和稳定的材料结构。氢氧化钾改性增加了其比表面积,使生物炭的孔隙结构更均匀,主要为微孔结构。四种改性生物炭的比表面积分别为521.07 m²/g、581.85 m²/g、304.99 m²/g和429.97 m²/g。随着生物炭中OH官能团增加,生物炭对Pb(ii)的吸附容量大幅提高。茎髓生物炭吸附效果最佳,吸附量为99.95 mg/g,去除率为50.35%。准二级模型和朗缪尔吸附等温线模型能较好地描述吸附过程,表明铅的吸附为单层吸附且伴有化学吸附。可以得出结论,生物质与聚乙烯共热解及改性可能有利于提高生物炭性能。除了共热解产生的合成气和生物油外,生物炭可能是一种有商业价值的副产品,可用于去除水中重金属,尤其是茎髓生物炭。
