Rahimi Mohammad Ghasem, Wang Anqi, Ma Guojun, Han Ning, Chen Yunfa
State Key Laboratory of Multiphase Complex Systems, Institute of Process Engineering, Chinese Academy of Sciences P.O. Box 353 Beijing 100190 PR China
Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences Beijing 100049 China.
RSC Adv. 2020 Nov 10;10(67):40916-40922. doi: 10.1039/d0ra05157h. eCollection 2020 Nov 9.
Nowadays, it is necessary and challenging to prepare monolithic catalysts, which are ready for use, preventing the tedious and complicated integration procedure of the powder materials onto a porous substrate. Herein, CuO nanoparticles are successfully synthesized onto a porous Cu foam in one pot the surface oxidation, coordination and precipitation reactions in a NHOH and HCl solution, and the optimum synthesis conditions are a NH : HCl ratio of 1 : 0.9, oxidation temperature of 80 °C and time of 18 h. The obtained CuO/Cu catalyst (mostly <100 nm) shows a highly active O decomposition performance with >98% and >80% conversion efficiency in dry and 90% relative humidity air for >10 h at an O concentration of 20 ppm and a gas hourly space velocity of 12 500 h. The high efficiency can be attributed to the porous Cu foam providing a large contact area, abundant crystal defects in the nanometer-sized CuO materials serving as the active sites, and also to the Schottky barrier formed in the CuO/Cu interface facilitating the electron transfer for O degradation. All these results show the potency of the easily fabricated monolithic CuO/Cu catalyst for the highly efficient O contaminant removal.
如今,制备整体式催化剂既必要又具有挑战性,这种催化剂可直接使用,避免了将粉末材料繁琐复杂地整合到多孔载体上的过程。在此,通过在NH₄OH和HCl溶液中的表面氧化、配位和沉淀反应,在一个反应釜中成功地在多孔泡沫铜上合成了CuO纳米颗粒,最佳合成条件为NH₄⁺:HCl比例为1:0.9、氧化温度为80℃、时间为18小时。所制备的CuO/Cu催化剂(大多<100nm)在20ppm的O₂浓度和12500h⁻¹的气体时空速下,在干燥空气和90%相对湿度的空气中均表现出高效的O₂分解性能,转化率分别>98%和>80%,且在>10h内保持稳定。这种高效率可归因于多孔泡沫铜提供了较大的接触面积,纳米尺寸的CuO材料中丰富的晶体缺陷作为活性位点,以及CuO/Cu界面形成的肖特基势垒促进了O₂降解的电子转移。所有这些结果表明,这种易于制备的整体式CuO/Cu催化剂在高效去除O₂污染物方面具有潜力。
