Steen Jorn D, Volker Anouk, Duijnstee Daniël R, Sardjan Andy S, Browne Wesley R
Molecular Inorganic Chemistry, Stratingh Institute for Chemistry, Faculty of Science and Engineering, University of Groningen, Nijenborgh 4, Groningen 9747AG, Netherlands.
J Phys Chem C Nanomater Interfaces. 2022 May 5;126(17):7680-7687. doi: 10.1021/acs.jpcc.2c00416. Epub 2022 Apr 20.
Thiophenol is a model compound used in the study of self-assembly of arylthiols on gold surfaces. In particular, changes in the surface-enhanced Raman scattering (SERS) spectra of these self-assembled monolayers (SAMs) with a change of conditions have been ascribed to, for example, differences in orientation with respect to the surface, protonation state, and electrode potential. Here, we show that potential-induced changes in the SERS spectra of SAMs of thiophenol on electrochemically roughened gold surfaces can be due to local pH changes at the electrode. The changes observed during the potential step and cyclic voltammetry experiments are identical to those induced by acid-base switching experiments in a protic solvent. The data indicate that the potential-dependent spectral changes, assigned earlier to changes in molecular orientation with respect to the surface, can be ascribed to changes in the pH locally at the electrode. The pH at the electrode can change as much as several pH units during electrochemical measurements that reach positive potentials where oxidation of adventitious water can occur. Furthermore, once perturbed by applying positive potentials, the pH at the electrode takes considerable time to recover to that of the bulk solution. It is noted that the changes in pH even during cyclic voltammetry in organic solvents can be equivalent to the addition of strong acids, such as CFSOH, and such effects should be considered in the study of the redox chemistry of pH-sensitive redox systems and potential-dependent SERS in particular.
苯硫酚是用于研究芳基硫醇在金表面自组装的模型化合物。特别是,这些自组装单分子层(SAMs)的表面增强拉曼散射(SERS)光谱随条件变化的情况,例如,已归因于相对于表面的取向差异、质子化状态和电极电位。在这里,我们表明,在电化学粗糙化的金表面上,苯硫酚SAMs的SERS光谱中由电位诱导的变化可能是由于电极处的局部pH变化。在电位阶跃和循环伏安实验中观察到的变化与在质子溶剂中进行的酸碱切换实验所诱导的变化相同。数据表明,早期归因于分子相对于表面取向变化的电位依赖性光谱变化,可归因于电极处局部pH的变化。在达到可能发生外来水氧化的正电位的电化学测量过程中,电极处的pH变化可达几个pH单位。此外,一旦施加正电位使其受到扰动,电极处的pH需要相当长的时间才能恢复到本体溶液的pH。需要注意的是,即使在有机溶剂中的循环伏安过程中,pH的变化也可能相当于加入了强酸,如CFSOH,在研究对pH敏感的氧化还原系统的氧化还原化学,特别是电位依赖性SERS时,应考虑这种影响。
