Double-Network Polymer Electrolytes with Ionic Liquids for Lithium Metal Batteries.

Solid-state polymer electrolytes have become promising candidates for high-energy-density lithium metal batteries (LMBs). However, they suffer from low ionic conductivities at room temperature. In this work, two types of composite polymer electrolytes based on a double-network polymer, an ionic liquid (IL) of 1-butyl-1-methylpyrrolidinium bis(trifluoromethanesulfonyl) imide (PyrTFSI) or 1-ethyl-3-methylimidazolium bis((trifluoromethyl)sulfonyl) imide (EmimTFSI), and bis(trifluoromethane)sulfonamide lithium salt (LiTFSI) were prepared by a facile one-pot method. The two types of CPEs possess good mechanical properties, excellent thermal stability, and high ionic conductivities greater than 10 S cm at 20 °C with 26 wt% IL. The performance diversity of the CPEs was also carefully investigated through a series of electrochemical measurements. Although the CPEs containing EmimTFSI show higher ionic conductivities than those of CPEs with PyrTFSI, the latter ones have wider electrochemical stability windows and better resistance to the growth of lithium dendrites. Moreover, CPE with 34 wt% PyrTFSI leads to Li/LiFePO batteries with favorable rate capability and cycling stability and a columbic efficiency of 98.8% at 20 °C, which suggests that CPEs are promising for practical application in solid-state LMBs.
