Institute for Chemistry and Biology of the Marine Environment (ICBM), Carl von Ossietzky University of Oldenburg, 26129, Oldenburg, Germany.
Anal Bioanal Chem. 2022 Nov;414(27):7839-7854. doi: 10.1007/s00216-022-04317-8. Epub 2022 Oct 5.
B vitamins have high microbiological relevance in the marine environment, but their very low concentrations and the chemical heterogeneity of the individual vitamins make their analysis challenging. Mass spectrometric analysis of B vitamins in environmental samples at trace levels has mainly been performed using triple quadrupole mass spectrometers operated in targeted analysis mode. The development of such a method can be laborious and error prone. Additionally, high-resolution mass spectrometers can be used to measure a sample in full scan mode and subsequently search the total ion current chromatogram for extracted ion chromatograms of targeted vitamins. Three different analytical approaches for trace analysis of all B vitamins and some of their biosynthetic precursors were optimized and compared on two different mass spectrometers. A triple quadrupole mass spectrometer in selected reaction monitoring mode, and a high-resolution orbitrap mass spectrometer in parallel reaction monitoring, as well as in full scan mode were employed. Detection limits down to 10 ng/L were achieved with all three techniques. The methods were applied to a marine water sample from the North Sea and to the cell extract of a bacterial culture of Phaeobacter inhibens. Most vitamins and precursors were found in the bacterial cell extract and the seawater sample with all three measuring methods. The results of this study emphasize that, in addition to tandem mass spectrometry, high-resolution full scan mass spectrometry is a promising technique for the simultaneous detection of structurally diverse B vitamins in complex natural samples. This enables highly sensitive measurements without loss of detailed mass spectrometric information, which is inevitable when using a triple quadrupole system in MS/MS mode.
B 族维生素在海洋环境中具有很高的微生物相关性,但由于其浓度非常低,且各种维生素的化学性质存在差异,因此分析起来具有一定挑战性。痕量环境样品中 B 族维生素的质谱分析主要使用三重四极杆质谱仪,以靶向分析模式进行。开发这种方法可能既繁琐又容易出错。此外,还可以使用高分辨率质谱仪以全扫描模式测量样品,并随后在总离子流色谱图中搜索目标维生素的提取离子色谱图。本研究优化并比较了三种不同的痕量分析方法,用于所有 B 族维生素及其部分生物合成前体的痕量分析,这三种方法分别是:三重四极杆质谱仪的选择反应监测模式、高分辨率轨道阱质谱仪的平行反应监测模式以及全扫描模式。这三种技术的检测限均达到 10 ng/L 以下。这三种方法被应用于北海海水样本和假单胞菌属抑制菌的细菌培养物的细胞提取物中。所有三种测量方法都在细菌细胞提取物和海水中发现了大多数维生素和前体。本研究结果强调,除串联质谱法外,高分辨率全扫描质谱法也是一种很有前途的技术,可用于同时检测复杂天然样品中结构多样的 B 族维生素。这种方法可以在不损失详细质谱信息的情况下进行高灵敏度测量,而当在 MS/MS 模式下使用三重四极杆系统时,这种信息必然会丢失。
