College of Smart Energy, Shanghai Jiao Tong University, No. 800 Dongchuan Road, Shanghai, 200240, China.
China-UK Low Carbon College, Shanghai Jiao Tong University, No. 3 Yinlian Road, Shanghai, 201306, China.
Adv Sci (Weinh). 2023 Jun;10(16):e2207253. doi: 10.1002/advs.202207253. Epub 2023 Apr 5.
Supported polyethyleneimine (PEI) adsorbent is one of the most promising commercial direct air capture (DAC) adsorbents with a long research history since 2002. Although great efforts have been input, there are still limited improvements for this material in its CO capacity and adsorption kinetics under ultradilute conditions. Supported PEI also suffers significantly reduced adsorption capacities when working at sub-ambient temperatures. This study reports that mixing diethanolamine (DEA) into supported PEI can increase 46% and 176% of pseudoequilibrium CO capacities at DAC conditions compared to the supported PEI and DEA, respectively. The mixed DEA/PEI functionalized adsorbents maintain the adsorption capacity at sub-ambient temperatures of -5 to 25 °C. In comparison, a 55% reduction of CO capacity is observed for supported PEI when the operating temperature decreases from 25 to -5 °C. In addition, the supported mixed DEA/PEI with a ratio of 1:1 also shows fast desorption kinetics at temperatures as low as 70 °C, resulting in maintaining high thermal and chemical stability over 50 DAC cycles with a high average CO working capacity of 1.29 mmol g . These findings suggest that the concept of "mixed amine", widely studied in the solvent system, is also practical to supported amine for DAC applications.
负载型聚乙烯亚胺(PEI)吸附剂是最有前途的商业直接空气捕获(DAC)吸附剂之一,自 2002 年以来已有很长的研究历史。尽管已经投入了大量的努力,但该材料在超稀条件下的 CO 容量和吸附动力学方面的改进仍然有限。在亚环境温度下工作时,负载型 PEI 的吸附容量也会显著降低。本研究表明,将二乙醇胺(DEA)混入负载型 PEI 中,可以分别将 DAC 条件下的拟平衡 CO 容量提高 46%和 176%。与负载型 PEI 和 DEA 相比,混合 DEA/PEI 功能化吸附剂在-5 至 25°C 的亚环境温度下保持吸附容量。相比之下,当操作温度从 25°C 降低到-5°C 时,负载型 PEI 的 CO 容量降低了 55%。此外,负载型混合 DEA/PEI 的比例为 1:1 时,在 70°C 时也表现出快速解吸动力学,从而在 50 次 DAC 循环中保持高热和化学稳定性,平均 CO 工作容量高达 1.29mmol g -1 。这些发现表明,在溶剂体系中广泛研究的“混合胺”概念对于 DAC 应用中的负载型胺也是实用的。
