Onuma Hiroaki, Sakai Kenichiro, Arai Yoshiyasu, Torigoe Ichiro, Tomori Masaki, Sakaki Kyohei, Hirai Takashi, Egawa Satoru, Kobayashi Yutaka, Okawa Atsushi, Yoshii Toshitaka
Department of Orthopedic Surgery, Saiseikai Kawaguchi General Hospital, 5-11-5 Nishikawaguchi, Kawaguchi-shi 332-8558, Japan.
Department of Orthopedic Surgery, Tokyo Medical and Dental University, 1-5-45 Yushima, Bunkyo Ward, Tokyo 113-8519, Japan.
J Clin Med. 2023 Apr 16;12(8):2898. doi: 10.3390/jcm12082898.
Anterior decompression and fusion (ADF) using the floating method for cervical ossification of the posterior longitudinal ligament (OPLL) is an ideal surgical technique, but it has a specific risk of insufficient decompression caused by the impingement of residual ossification. Augmented reality (AR) support is a novel technology that enables the superimposition of images onto the view of a surgical field. AR technology was applied to ADF for cervical OPLL to facilitate intraoperative anatomical orientation and OPLL identification. In total, 14 patients with cervical OPLL underwent ADF with microscopic AR support. The outline of the OPLL and the bilateral vertebral arteries was marked after intraoperative CT, and the reconstructed 3D image data were transferred and linked to the microscope. The AR microscopic view enabled us to visualize the ossification outline, which could not be seen directly in the surgical field, and allowed sufficient decompression of the ossification. Neurological disturbances were improved in all patients. No cases of serious complications, such as major intraoperative bleeding or reoperation due to the postoperative impingement of the floating OPLL, were registered. To our knowledge, this is the first report of the introduction of microscopic AR into ADF using the floating method for cervical OPLL with favorable clinical results.
采用漂浮法对颈椎后纵韧带骨化症(OPLL)进行前路减压融合术(ADF)是一种理想的手术技术,但存在因残留骨化组织撞击导致减压不充分的特定风险。增强现实(AR)支持是一项能够将图像叠加到手术视野上的新技术。AR技术应用于颈椎OPLL的ADF手术,以促进术中解剖定位和OPLL识别。共有14例颈椎OPLL患者在显微AR支持下接受了ADF手术。术中CT后标记OPLL和双侧椎动脉的轮廓,并将重建的3D图像数据传输并连接到显微镜。AR显微镜视图使我们能够可视化在手术视野中无法直接看到的骨化轮廓,并实现对骨化组织的充分减压。所有患者的神经功能障碍均得到改善。未记录到严重并发症,如术中大出血或因漂浮OPLL术后撞击而再次手术的病例。据我们所知,这是首次将显微AR引入采用漂浮法治疗颈椎OPLL的ADF手术并取得良好临床效果的报告。
