利用深度学习算法检测室内环境下不同光照条件下生长的缺陷生菜苗。
Detection of Defective Lettuce Seedlings Grown in an Indoor Environment under Different Lighting Conditions Using Deep Learning Algorithms.
机构信息
Graduate School of Science and Technology, University of Tsukuba, 1-1-1 Tennodai, Tsukuba 305-8577, Japan.
Institute of Life and Environmental Sciences, University of Tsukuba, 1-1-1 Tennodai, Tsukuba 305-8577, Japan.
出版信息
Sensors (Basel). 2023 Jun 21;23(13):5790. doi: 10.3390/s23135790.
Sorting seedlings is laborious and requires attention to identify damage. Separating healthy seedlings from damaged or defective seedlings is a critical task in indoor farming systems. However, sorting seedlings manually can be challenging and time-consuming, particularly under complex lighting conditions. Different indoor lighting conditions can affect the visual appearance of the seedlings, making it difficult for human operators to accurately identify and sort the seedlings consistently. Therefore, the objective of this study was to develop a defective-lettuce-seedling-detection system under different indoor cultivation lighting systems using deep learning algorithms to automate the seedling sorting process. The seedling images were captured under different indoor lighting conditions, including white, blue, and red. The detection approach utilized and compared several deep learning algorithms, specifically CenterNet, YOLOv5, YOLOv7, and faster R-CNN to detect defective seedlings in indoor farming environments. The results demonstrated that the mean average precision (mAP) of YOLOv7 (97.2%) was the highest and could accurately detect defective lettuce seedlings compared to CenterNet (82.8%), YOLOv5 (96.5%), and faster R-CNN (88.6%). In terms of detection under different light variables, YOLOv7 also showed the highest detection rate under white and red/blue/white lighting. Overall, the detection of defective lettuce seedlings by YOLOv7 shows great potential for introducing automated seedling-sorting systems and classification under actual indoor farming conditions. Defective-seedling-detection can improve the efficiency of seedling-management operations in indoor farming.
对幼苗进行分拣既费力又需要注意识别损伤。将健康的幼苗与受损或有缺陷的幼苗分开是室内种植系统中的一项关键任务。然而,手动对幼苗进行分拣可能具有挑战性且耗时,特别是在复杂的光照条件下。不同的室内光照条件会影响幼苗的视觉外观,使得人工操作员难以准确且一致地识别和分拣幼苗。因此,本研究的目的是使用深度学习算法开发一种在不同室内栽培照明系统下用于检测缺陷生菜幼苗的系统,以实现幼苗分拣过程的自动化。在不同的室内光照条件下采集幼苗图像,包括白色、蓝色和红色。该检测方法利用并比较了几种深度学习算法,特别是 CenterNet、YOLOv5、YOLOv7 和 faster R-CNN,以在室内农业环境中检测缺陷幼苗。结果表明,YOLOv7 的平均精度(mAP)(97.2%)最高,与 CenterNet(82.8%)、YOLOv5(96.5%)和 faster R-CNN(88.6%)相比,能够更准确地检测缺陷生菜幼苗。在不同光照变量下的检测方面,YOLOv7 在白光和红蓝白光照下也表现出了最高的检测率。总的来说,YOLOv7 对缺陷生菜幼苗的检测为在实际室内农业条件下引入自动化幼苗分拣系统和分类提供了很大的潜力。缺陷幼苗检测可以提高室内农业中幼苗管理操作的效率。
