Department of Electronic Engineering, University of Sevilla, 41092 Sevilla, Spain.
Sensors (Basel). 2023 Jun 23;23(13):5844. doi: 10.3390/s23135844.
Depleted Monolithic Active Pixel Sensors (DMAPSs) are foreseen as an interesting choice for future high-energy physics experiments, mainly because of the reduced fabrication costs. However, they generally offer limited time resolution due to the stringent requirements of area and power consumption imposed by the targeted spatial resolution. This work describes a methodology to optimize the design of time-to-digital converter (TDC)-based timing electronics that takes advantage of the asymmetrical shape of the pulse at the output of the analog front-end (AFE). Following that methodology, a power and area efficient implementation fully compatible with the RD50-MPW3 solution is proposed. Simulation results show that the proposed solution offers a time resolution of 2.08 ns for a range of energies from 1000 e to 20,000 e, with minimum area and zero quiescent in-pixel power consumption.
耗尽型整体式像素传感器 (DMAPS) 由于制造成本降低,预计将成为未来高能物理实验的一个有趣选择。然而,由于目标空间分辨率对面积和功耗的严格要求,它们通常提供的时间分辨率有限。本工作描述了一种优化基于时间数字转换器 (TDC) 的定时电子设计的方法,该方法利用模拟前端 (AFE) 输出处脉冲的不对称形状。根据该方法,提出了一种与 RD50-MPW3 解决方案完全兼容的、具有功率和面积效率的实现方案。仿真结果表明,所提出的解决方案在 1000e 到 20000e 的能量范围内提供了 2.08ns 的时间分辨率,具有最小的面积和零静态像素内功耗。
