A novel approach to determining augmented bone volume in intraoral bone block augmentation using an intraoral scanner: an in vitro study.

INTRODUCTION

Bone augmentation procedures are established tools for reshaping the alveolar ridge and increasing bone volume. Different approaches are being used to measure postoperative bone volume gain. This study aimed to develop an objective and automated volume measurement tool equally as precise as manual slice-by-slice annotation.

MATERIALS AND METHODS

To evaluate the proposed workflow, we performed an in vitro study with 20 pig mandibles that were grafted using three different grafting techniques-autogenous full block, split block bone and shell augmentation. The pig jaws were scanned pre- and postoperatively using an intraoral scanner. The resulting surface files (baseline, full block, split block, shell) were processed using the new volume-measuring workflow as well as using manual slice-by-slice annotation at baseline (t0) and at 6 months (t1) using the same population. Two TOSTs (Test of One-Sided Significance) and NHSTs (Null Hypothesis Significance Test) were used to compare the two workflows. The intra-rater reliability between t0 and t1 was determined using intraclass correlation coefficients.

RESULTS

The mean difference for the full block augmentation technique was - 0.015 cm (p < 0.001); for the split block technique, it was - 0.034 cm p = 0.01, and for the shell technique, it was - 0.042 cm. All results were statistically not different from zero and statistically equivalent to zero. The results also showed an excellent absolute intra-rater agreement.

CONCLUSIONS

The semiautomatic volume measurement established in this article achieves comparable results to manual slice-by-slice measuring in determining volumes on STL files generated by intraoral scanners and shows an excellent intra-rater reliability.
