Anker Marvin, Yousefi-Darani Abdolrahim, Zettel Viktoria, Paquet-Durand Olivier, Hitzmann Bernd, Krupitzer Christian
Department of Food Informatics and Computational Science Hub, University of Hohenheim, 70599 Stuttgart, Germany.
Department of Process Analytics and Cereal Science, University of Hohenheim, 70599 Stuttgart, Germany.
Sensors (Basel). 2023 Sep 6;23(18):7681. doi: 10.3390/s23187681.
Sourdough can improve bakery products' shelf life, sensory properties, and nutrient composition. To ensure high-quality sourdough, the fermentation has to be monitored. The characteristic process variables for sourdough fermentation are pH and the degree of acidity measured as total titratable acidity (TTA). The time- and cost-intensive offline measurement of process variables can be improved by utilizing online gas measurements in prediction models. Therefore, a gas sensor array (GSA) system was used to monitor the fermentation process of sourdough online by correlation of exhaust gas data with offline measurement values of the process variables. Three methods were tested to utilize the extracted features from GSA to create the models. The most robust prediction models were achieved using a PCA (Principal Component Analysis) on all features and combined two fermentations. The calibrations with the extracted features had a percentage root mean square error (RMSE) from 1.4% to 12% for the pH and from 2.7% to 9.3% for the TTA. The coefficient of determination (R2) for these calibrations was 0.94 to 0.998 for the pH and 0.947 to 0.994 for the TTA. The obtained results indicate that the online measurement of exhaust gas from sourdough fermentations with gas sensor arrays can be a cheap and efficient application to predict pH and TTA.
酸面团可以延长烘焙产品的保质期、改善其感官特性和营养成分。为确保酸面团的高质量,必须对发酵过程进行监测。酸面团发酵的特征过程变量是pH值和以总可滴定酸度(TTA)衡量的酸度。通过在预测模型中利用在线气体测量,可以改进对过程变量进行的耗时且成本高的离线测量。因此,使用气体传感器阵列(GSA)系统,通过将废气数据与过程变量的离线测量值相关联,来在线监测酸面团的发酵过程。测试了三种方法,利用从GSA提取的特征来创建模型。使用主成分分析(PCA)对所有特征进行分析并结合两次发酵,获得了最稳健的预测模型。利用提取的特征进行校准,pH值的百分比均方根误差(RMSE)为1.4%至12%,TTA的百分比均方根误差为2.7%至9.3%。这些校准的决定系数(R2),pH值为0.94至0.998,TTA为0.947至0.994。所得结果表明,利用气体传感器阵列对酸面团发酵废气进行在线测量,可成为预测pH值和TTA的一种廉价且高效的应用。
