BACKGROUND

The heel is a complex anatomical region and is very often the source of pain complaints. The medial heel contains a number of structures, capable of compressing the main nerves of the region and knowing its anatomical topography is mandatory. The purpose of this work is to evaluate if tibial nerve (TN) and its main branches relate to the main anatomical landmarks of the ankle's medial side and if so, do they have a regular path after emerging from TN.

METHODS

The distal part of the legs, ankles and feet of 12 Thiel embalmed cadavers were dissected. The pattern of the branches of the TN was registered and the measurements were performed according to the Dellon-McKinnon malleolar-calcaneal line (DML) and the Heimkes Triangle (HT).

RESULTS

The TN divided proximal to DML in 87.5%, on top of the DML in 12,5% and distal in none of the feet. The Baxter's nerve (BN) originated proximally in 50%, on top of the DML in 12,5% and distally in 37.5% of the cases. There was a strong and significant correlation between the length of DML and the distance from the center of the medial malleolus (MM) to the lateral plantar nerve (LPN), medial plantar (MPN) nerve, BN and Medial Calcaneal Nerve (MCN) (ρ: 0.910, 0.866, 0.970 and 0.762 respectively, p <  0.001).

CONCLUSIONS

In our sample the TN divides distal to DML in none of the cases. We also report a strong association between ankle size and the distribution of the MPN, LPN, BN and MCN. We hypothesize that location of these branches on the medial side of the ankle could be more predictable if we take into consideration the distance between the MM and the medial process of the calcaneal tuberosity.
