Jiang Chendan, Zhang Wentai, Wang He, Jiao Yixi, Fang Yi, Feng Feng, Feng Ming, Wang Renzhi
Department of Neurosurgery, Chinese Academy of Medical Sciences and Peking Union Medical College, Peking Union Medical College Hospital, Beijing 100730, China.
Department of Neurosurgery, Xuanwu Hospital, Capital Medical University, China International Neuroscience Institute, Beijing 100053, China.
Bioengineering (Basel). 2023 Nov 8;10(11):1295. doi: 10.3390/bioengineering10111295.
Cystic lesions are common lesions of the sellar region with various pathological types, including pituitary apoplexy, Rathke's cleft cyst, cystic craniopharyngioma, etc. Suggested surgical approaches are not unique when dealing with different cystic lesions. However, cystic lesions with different pathological types were hard to differentiate on MRI with the naked eye by doctors. This study aimed to distinguish different pathological types of cystic lesions in the sellar region using preoperative magnetic resonance imaging (MRI). Radiomics and deep learning approaches were used to extract features from gadolinium-enhanced MRIs of 399 patients enrolled at Peking Union Medical College Hospital over the past 15 years. Paired imaging differentiations were performed on four subtypes, including pituitary apoplexy, cystic pituitary adenoma (cysticA), Rathke's cleft cyst, and cystic craniopharyngioma. Results showed that the model achieved an average AUC value of 0.7685. The model based on a support vector machine could distinguish cystic craniopharyngioma from Rathke's cleft cyst with the highest AUC value of 0.8584. However, distinguishing cystic apoplexy from pituitary apoplexy was difficult and almost unclassifiable with any algorithms on any feature set, with the AUC value being only 0.6641. Finally, the proposed methods achieved an average Accuracy of 0.7532, which outperformed the traditional clinical knowledge-based method by about 8%. Therefore, in this study, we first fill the gap in the existing literature and provide a non-invasive method for accurately differentiating between these lesions, which could improve preoperative diagnosis accuracy and help to make surgery plans in clinical work.
囊性病变是鞍区常见病变,有多种病理类型,包括垂体卒中、拉克氏囊肿、囊性颅咽管瘤等。处理不同的囊性病变时,建议的手术入路并非唯一。然而,不同病理类型的囊性病变在磁共振成像(MRI)上医生很难用肉眼区分。本研究旨在利用术前磁共振成像(MRI)鉴别鞍区不同病理类型的囊性病变。采用放射组学和深度学习方法从北京协和医院过去15年收治的399例患者的钆增强MRI中提取特征。对垂体卒中、囊性垂体腺瘤(cysticA)、拉克氏囊肿和囊性颅咽管瘤这四种亚型进行配对成像鉴别。结果显示,该模型的平均曲线下面积(AUC)值为0.7685。基于支持向量机的模型能够将囊性颅咽管瘤与拉克氏囊肿区分开来,最高AUC值为0.8584。然而,区分囊性垂体腺瘤与垂体卒中很困难,几乎无法用任何算法在任何特征集上进行分类,AUC值仅为0.6641。最后,所提出的方法平均准确率为0.7532,比传统的基于临床知识的方法高出约8%。因此,在本研究中,我们首先填补了现有文献中的空白,提供了一种准确区分这些病变的非侵入性方法,这可以提高术前诊断的准确性,并有助于在临床工作中制定手术计划。
