Traditional respiratory rehabilitation training fails to achieve visualization and quantification of respiratory data in improving problems such as decreased lung function and dyspnea in people with respiratory disorders, and the respiratory rehabilitation training process is simple and boring. Therefore, this article designs a biofeedback respiratory rehabilitation training system based on virtual reality technology. It collects respiratory data through a respiratory sensor and preprocesses it. At the same time, it combines the biofeedback respiratory rehabilitation training virtual scene to realize the interaction between respiratory data and virtual scenes. This drives changes in the virtual scene, and finally the respiratory data are fed back to the patient in a visual form to evaluate the improvement of the patient's lung function. This paper conducted an experiment with 10 participants to evaluate the system from two aspects: training effectiveness and user experience. The results show that this system has significantly improved the patient's lung function. Compared with traditional training methods, the respiratory data are quantified and visualized, the rehabilitation training effect is better, and the training process is more active and interesting.
