Department of Bioengineering, Imperial College London, London, UK.
Neuroscience Research Australia, Sydney and University of New South Wales, Sydney, Australia.
J Physiol. 2024 Jan;602(2):281-295. doi: 10.1113/JP285319. Epub 2023 Dec 7.
In two papers dated 1928 to 1929 in The Journal of Physiology, Edgar Adrian and Detlev Bronk described recordings from motor nerve and muscle fibres. The recordings from motor nerve fibres required progressive dissection of the nerve until a few fibres remained, from which isolated single fibre activity could be detected. The muscle fibre recordings were performed in humans during voluntary contractions with an intramuscular electrode - the concentric needle electrode - that they describe for the first time in the second paper. They recognised that muscle fibres would respond to each impulse sent by the innervating motor neurone and that therefore muscle fibre recordings provided information on the times of activation of the motor nerve fibres which were as accurate as a direct record from the nerve. These observations and the description of the concentric needle electrode opened the era of motor unit recordings in humans, which have continued for almost a century and have provided a comprehensive view of the neural control of movement at the motor unit level. Despite important advances in technology, many of the principles of motor unit behaviour that would be investigated in the subsequent decades were canvassed in the two papers by Adrian and Bronk. For example, they described the concomitant motor neurones' recruitment and rate coding for force modulation, synchronisation of motor unit discharges, and the dependence of discharge rate on motor unit recruitment threshold. Here, we summarise their observations and discuss the impact of their work. We highlight the advent of the concentric needle, and its subsequent influence on motor control research.
在 1928 年至 1929 年期间,埃德加·艾德里安(Edgar Adrian)和德特勒夫·布朗克(Detlev Bronk)在《生理学杂志》(The Journal of Physiology)上发表了两篇论文,描述了运动神经和肌肉纤维的记录。从运动神经纤维的记录需要逐步解剖神经,直到只剩下几根纤维,从中可以检测到孤立的单纤维活动。肌肉纤维的记录是在人类自愿收缩期间进行的,使用的是肌内电极——同心针电极——他们在第二篇论文中首次对此进行了描述。他们认识到肌肉纤维会对支配运动神经元发出的每一个冲动做出反应,因此肌肉纤维的记录提供了关于运动神经纤维激活时间的信息,其准确性与直接从神经记录一样高。这些观察结果和同心针电极的描述开创了人类运动单位记录的时代,这一时代已经持续了近一个世纪,并提供了对运动单位水平神经控制的全面了解。尽管技术有了重要的进步,但在随后的几十年中,艾德里安和布朗克的这两篇论文中也探讨了许多运动单位行为的原理。例如,他们描述了伴随运动神经元的募集和力调制的速率编码、运动单位放电的同步以及放电率对运动单位募集阈值的依赖。在这里,我们总结了他们的观察结果,并讨论了他们工作的影响。我们强调了同心针的出现,以及它对运动控制研究的后续影响。
