Depth-Dependent Strain Model (1D) for Anisotropic Fibrils in Articular Cartilage.

The mechanical response of articular cartilage (AC) under compression is anisotropic and depth-dependent. AC is osmotically active, and its intrinsic osmotic swelling pressure is balanced by its collagen fibril network. This mechanism requires the collagen fibers to be under a state of tensile pre-strain. A simple mathematical model is used to explain the depth-dependent strain calculations observed in articular cartilage under 1D axial compression (perpendicular to the articular surface). The collagen fibers are under pre-strain, influenced by proteoglycan concentration (fixed charged density, FCD) and collagen stiffness against swelling stress. The stiffness is introduced in our model as an anisotropic modulus that varies with fibril orientation through tissue depth. The collagen fibers are stiffer to stretching parallel to their length than perpendicular to it; when combined with depth-varying FCD, the model successfully predicts how tissue strains decrease with depth during compression. In summary, this model highlights that the mechanical properties of cartilage depend not only on proteoglycan concentration but also on the intrinsic properties of the pre-strained collagen network. These properties are essential for the proper functioning of articular cartilage.
