Experimental Study on Flame Chemical Composition of Coal and Ammonia Gas-Solid Jet in Flat Flame Burner.

Ammonia as a fuel to partially or completely replace fossil fuels is one of the effective ways to reduce carbon dioxide, and the research on ammonia coal cocombustion is of great significance. The combustion characteristics of ammonia are very different from those of pulverized coal, resulting in the ignition and emission characteristics of ammonia and pulverized coal gas flow that is different from traditional pulverized coal flame. In this paper, the effect of pulverized coal concentration in coal and ammonia mixed combustion jet on the ignition distance and gas-phase components at different positions of the jet flame were studied experimentally on the flat flame burner, and the conditions of ignition and ignition stability of coal and ammonia gas-solid fuel were expounded. It was found that the ammonia mixed with pulverized coal changed the temperature field of the flat flame burner and therefore the ignition characteristics of the jet were changed. The ignition delay time at the same jet speed was positively correlated with the pulverized coal concentration, but when the pulverized coal concentration continued to decrease, the influence on the ignition delay time gradually became smaller. The composition of coal ammonia gas-solid fuel changed the heat transfer path and share during combustion, and finally, the flame temperature was negatively correlated with the concentration of pulverized coal. Therefore, the reduction of the pulverized coal concentration was conducive to the stable combustion of coal ammonia mixed fuel. When HAB = 100 mm, the conversion rate of fuel N to NO per unit mass of coal ammonia mixture increased with the increase of pulverized coal concentration. The NO production amount first increased and then decreased with the increase of pulverized coal concentration, and the amount of NO and NO decreased rapidly with the increase of HAB. The proportion of NO in NO exceeded 94%, which was conducive to achieving low nitrogen combustion of coal and ammonia gas-solid fuel. In general, the O concentration in the ammonia coal jet flame decreased, the flue gas temperature, and NO and CO generation increased after mixing ammonia, and the optimal pulverized coal concentration in this experiment was 0.41 kgc/kga (mass ratio of pulverized coal to the sum of N and NH).
