Reservoir characterization of the Abu Roash D Member through petrography and seismic interpretations in Southern Abu Gharadig Basin, Northern Western Desert, Egypt.

This research combines petrography and seismic analysis to assess the Upper Cretaceous Abu Roash (AR)/D's carbonate member composition in the Southwest Abu-Sennan oil field in the Southern Abu Gharadig Basin within the Northern Western Desert of Egypt. Various datasets were used, including petrographic thin sections, and electrical well logs for four stratigraphic wells (01, -02, -03, and, -04), along with a time domain seismic dataset covering the study area. Petrographic analysis across multiple depths and intervals has provided valuable insights. Well-01 demonstrates mud-wackstone with diverse mineral components at 1671-74 m MD, indicating favorable reservoir quality. Well-02 exhibits diverse compositions at intervals 1740-43 m MD and 1746-49 m MD, also showcasing good reservoir quality. Well-03 reveals a packstone rock type at 1662-65 m MD with favorable reservoir characteristics. Well-04 displays peloids Wack-Packstone and Oolitic Packstone at intervals 1764-67 m MD and 1770-73 m MD, respectively, both indicating good reservoir quality. Integrating the petrography and seismic attributes results concerning the structural level of AR/D concerning the used wells, it's evident that Well-03 stands out due to its relatively high structural level, drilled near a major fault, revealing distinct fracture sets that contribute to a notably high reservoir quality as depicted in the RMS amplitude and Ant track attributes maps. AR/D reservoir levels in wells 02, and, 04, are relatively positioned at structurally lower levels, and face challenges with overburden pressure and mechanical compaction, resulting in diminished facies quality for the reservoir. Seismic attributes like the Ant track and RMS amplitude indicated that the presence of fractures within the AR/D Member's carbonate is linked to the prevalence of interpreted normal faults. The implemented procedure in this research can be applied to enhance comprehension of AR/D carbonate reservoirs in adjacent regions, thereby increasing the hydrocarbon exploration possibilities.
