Westerlund Kristina, Oroujeni Maryam, Gestin Maxime, Clinton Jacob, Hani Rosly Alia, Tano Hanna, Vorobyeva Anzhelika, Orlova Anna, Eriksson Karlström Amelie, Tolmachev Vladimir
Department of Protein Science, School of Engineering Sciences in Chemistry, Biotechnology and Health, KTH Royal Institute of Technology, Stockholm 106 91, Sweden.
Department of Immunology, Genetics and Pathology, Uppsala University, Uppsala 751 23, Sweden.
ACS Pharmacol Transl Sci. 2024 Apr 29;7(5):1595-1611. doi: 10.1021/acsptsci.4c00106. eCollection 2024 May 10.
Affibody-mediated PNA-based pretargeting shows promise for HER2-expressing tumor radiotherapy. In our recent study, a 15-mer Z-HP15 affibody-PNA conjugate, in combination with a shorter 9-mer [Lu]Lu-HP16 effector probe, emerged as the most effective pretargeting strategy. It offered a superior tumor-to-kidney uptake ratio and more efficient tumor targeting compared to longer radiolabeled effector probes containing 12 or 15 complementary PNA bases. To enhance the production efficiency of our pretargeting system, we here introduce even shorter 6-, 7-, and 8-mer secondary probes, designated as HP19, HP21, and HP20, respectively. We also explore the replacement of the original 15-mer Z-HP15 primary probe with shorter 12-mer Z-HP12 and 9-mer Z-HP9 alternatives. This extended panel of shorter PNA-based probes was synthesized using automated microwave-assisted methods and biophysically screened in vitro to identify shorter probe combinations with the most effective binding properties. In a mouse xenograft model, we evaluated the biodistribution of these probes, comparing them to the Z-HP15:[Lu]Lu-HP16 combination. Tumor-to-kidney ratios at 4 and 144 h postinjection of the secondary probe showed no significant differences among the Z-HP9:[Lu]Lu-HP16, Z-HP9:[Lu]Lu-HP20, and the Z-HP15:[Lu]Lu-HP16 pairs. Importantly, tumor uptake significantly exceeded, by several hundred-fold, that of most normal tissues, with kidney uptake being the critical organ for radiation therapy. This suggests that using a shorter 9-mer primary probe, Z-HP9, in combination with 9-mer HP16 or 8-mer HP20 secondary probes effectively targets tumors while minimizing the dose-limiting kidney uptake of radionuclide. In conclusion, the Z-HP9:HP16 and Z-HP9:HP20 probe combinations offer good prospects for both cost-effective production and efficient in vivo pretargeting of HER2-expressing tumors.
基于亲和体介导的基于肽核酸的预靶向技术在HER2表达肿瘤放疗中显示出前景。在我们最近的研究中,一种15聚体Z-HP15亲和体-肽核酸偶联物,与较短的9聚体[镥]镥-HP16效应探针联合使用,成为最有效的预靶向策略。与含有12或15个互补肽核酸碱基的更长放射性标记效应探针相比,它提供了更高的肿瘤与肾脏摄取比以及更有效的肿瘤靶向性。为提高我们预靶向系统的生产效率,我们在此引入甚至更短的6聚体、7聚体和8聚体二级探针,分别命名为HP19、HP21和HP20。我们还探索用更短的12聚体Z-HP12和9聚体Z-HP9替代物替换原来的15聚体Z-HP15一级探针。使用自动化微波辅助方法合成了这一扩展的基于较短肽核酸的探针组,并在体外进行生物物理筛选,以鉴定具有最有效结合特性的较短探针组合。在小鼠异种移植模型中,我们评估了这些探针的生物分布,并将它们与Z-HP15:[镥]镥-HP16组合进行比较。注射二级探针后4小时和144小时的肿瘤与肾脏比在Z-HP9:[镥]镥-HP16、Z-HP9:[镥]镥-HP20和Z-HP15:[镥]镥-HP16配对之间无显著差异。重要的是,肿瘤摄取比大多数正常组织高出数百倍,肾脏摄取是放疗的关键器官。这表明使用更短的9聚体一级探针Z-HP9,与9聚体HP16或8聚体HP20二级探针联合使用,可有效靶向肿瘤,同时将放射性核素的剂量限制肾脏摄取降至最低。总之,Z-HP9:HP16和Z-HP9:HP20探针组合在HER2表达肿瘤的经济高效生产和体内有效预靶向方面都具有良好前景。
