Urinary tract infection (UTI) is one of the most common infectious diseases among children, but there is controversy regarding the use of preventive antibiotics for children first diagnosed with febrile pyelonephritis. To the best of our knowledge, no studies have addressed this issue by the deep learning technology. Therefore, in the current study, we conducted a study using renal static imaging data to investigate the need for preventive antibiotics on children first diagnosed with febrile pyelonephritis under 2 years old. The self-collected dataset comprised 64 children who did not require preventive antibiotic treatments and 112 children who did. Using several classic deep learning models, we verified that it is feasible to screen whether the first diagnosed children with febrile pyelonephritis require preventive antibacterial therapy, achieving a graded diagnosis. With the AlexNet model, we obtained accuracy of 84.05%, sensitivity of 81.71% and specificity of 86.70%, respectively. The experimental results indicate that deep learning technology could provide a new avenue to implement computer-assisted decision support for the diagnosis of the febrile pyelonephritis.
