BACKGROUND: No reports have shown histological changes before and after anti-C5 monoclonal antibody treatment in patients with atypical hemolytic uremic syndrome (aHUS). Here, we report a rare case of complement-mediated aHUS with a complement factor H (CFH) mutation and anti-CFH antibodies who underwent multiple kidney biopsies. CASE PRESENTATION: A 53-year-old woman developed aHUS with CFH gene mutation [c.3572C > T (p. Ser1191 Leu)] and anti-CFH antibodies. Her father had succumbed to acute kidney injury (AKI) in his 30 s. She exhibited AKI, thrombocytopenia, and hemolytic anemia with schistocytes. After improving the platelet count with one session of plasma exchange, a kidney biopsy was performed one month after the onset of symptoms. Blood vessel thrombosis, obvious endothelial swelling, endocapillary hypercellularity, and subendothelial exudative lesions in the glomeruli and arterioles were detected. Anti-C5 monoclonal antibody treatment with eculizumab immediately improved disease activity. A second biopsy 3 months later revealed marked improvement of endothelial injuries with residual membrane double contours and exudative lesions. A third biopsy at 17 months after gradual improvement of kidney function showed a further decrease of double contours along with alterations of the exudative lesions to fibrous intimal thickening. CONCLUSIONS: This is the first report showing the pathophysiology of aHUS in the kidneys and the efficacy of anti-C5 monoclonal antibody treatment by presenting serial kidney pathological features before and after anti-C5 monoclonal antibody treatment. Since her CFH mutation was considered the most important pathological condition, treatment centered on eculizumab was administered, resulting in a good long-term prognosis. In addition, kidney pathological resolution in aHUS occurred over 1 year after anti-C5 monoclonal antibody treatment.
